  • LC3F2-1-C3-05-1 A SMC Pneumatics Products Fittings For Linear Actuator

LC3F2-1-C3-05-1 A SMC Pneumatics Products Fittings For Linear Actuator

The SMC LC3F2-1-C3-05-1 is a motor output terminal cable specifically designed for the SMC LC3F2 series linear actuators. As one of the SMC pneumatics products, it is used to connect the motor output terminals of the actuators. This cable, with a length of 5 meters, is ···

  • Contact Us Contact On WhatsApp
  • 010-64225983

    +8613811814778

    info@zhongpingtech.com

    Building 26, Liyuan Community, Chaoyang District, Beijing, China

The SMC LC3F2-1-C3-05-1 is a motor output terminal cable specifically designed for the SMC LC3F2 series linear actuators. As one of the SMC pneumatics products, it is used to connect the motor output terminals of the actuators. This cable, with a length of 5 meters, is ideal for applications requiring longer wiring distances. It is one of the basic and high-quality pneumatic fittings.

LC3F2-1-C3-05-1 A SMC Pneumatics Products Fittings For Linear Actuator

Product Features

Cable Length: 5 meters.

Applicable Series: Designed specifically for the LC3F2 series linear actuators.

Connection Type: For CN3 motor output terminals.

Protection Function: Features current control to prevent motor and driver burnout.

Signal Control: Supports movement commands and thrust settings via ON/OFF signals.

Applications

As one of the most important pneumatic fittings, the LC3F2-1-C3-05-1 cable is widely used in industrial automation, including:

Automated Production Lines: Connects linear actuators to achieve precise position control.

Material Handling Equipment: Provides stable signal transmission for reliable operation. Most of the SMC pneumatics products are reliable.

Machine Tools: Suitable for applications requiring high-precision control.

Usage Instructions

1.    Installation Steps:

Ensure the cable is connected to the correct motor output terminal (CN3).

Check that the cable connections are secure to avoid looseness or poor contact.

After installation, perform a simple function test to ensure the cable is working properly.

2.    Precautions:

Avoid exposing the cable to high temperatures, humidity, or chemical substances. It is like other pneumatic fittings.

Regularly inspect the cable for wear and replace it if necessary.

When wiring, avoid crossing with other high-voltage or interference sources.

Frequently Asked Questions (FAQ):

1.    Can the cable length of LC3F2-1-C3-05-1 be customized?

The product is a standard model with a fixed cable length of 5 meters. For other lengths, contact SMC or an authorized dealer.

2.    Is this cable compatible with other brands of actuators?

The LC3F2-1-C3-05-1 is one of the SMC pneumatics products and is designed specifically for the SMC LC3F2 series and is not recommended for other brands or models.

3.    What is the protection rating of the cable?

The cable meets the IP67 protection rating, making it suitable for harsh environments.

4.    How to determine if the cable is damaged?

If the cable shows signs of wear, cracks, or unstable connections, replace it immediately. Additionally, if the device experiences signal interruptions or abnormalities during operation, the cable may be damaged.

5.    How to properly install the LC3F2-1-C3-05-1 cable?

Ensure the cable is connected to the correct motor output terminal (CN3).

Avoid routing the cable adjacent to high-voltage or high-current lines to prevent noise interference.

Use the specified tools for terminal crimping and ensure good insulation.

It is recommended to use shielded cable and ensure proper grounding to enhance interference resistance.

6.    What is the lifespan of the cable?

The cable has a long lifespan under normal conditions. However, in high-vibration or harsh environments, regular inspection and replacement are recommended just like other pneumatic fittings.

7.    How to perform a function test after installation?

After installation, perform a simple function test to ensure the cable is working properly:

Check if the power indicator light is on after powering up.

Input control signals and verify if the linear actuators operate as expected in terms of direction and speed.

8.    Does the cable need to be grounded?

Yes, the grounding terminal (FG terminal) of the cable must be grounded to prevent electric shock and fire.

Use a separate grounding wire and ensure the grounding distance is as short as possible.

9.    Does the cable support quick connect/disconnect?

The LC3F2-1-C3-05-1 cable features a standard CN3 connector that supports quick connect/disconnect for easy installation and maintenance.

10. How to troubleshoot if there is a problem with the cable?

If the electric actuator fails to start or operates unstably, follow these troubleshooting steps:

Check if the power voltage is within the range of 24VDC ±10%.

Verify if the power supply capacity meets the device’s requirements.

Ensure the connections to the CN3 motor output terminals are correct.

If the issue persists, contact SMC technical support for further assistance.
