The SMC LZ-NT30 is one of the pneumatic fittings and a specialized installation nut designed for electric actuators, primarily used to secure and connect components on the motor or rod side of the actuator. As one of the SMC fittings, it provides a stable mechanical connection to ensure reliability and stability during operation.



Product Specifications

    Applicable Series: LZB3 series electric actuators.

    Thread Specification: M20 x 1.5.

    Material: It is one of the SMC fittings and is made from high-strength aluminum alloy or stainless steel, depending on the model.

Product Structure and Design

The LZ-NT30 nut is a precision component designed specifically for electric actuators. Its key features include:

    High Strength: Made from durable materials, which is necessary for pneumatic fittings, to withstand high loads and frequent use.

    Precision Machining: The nut’s threads are precisely machined to match the actuator’s threads, reducing the risk of loosening or wear.

    Compact Design: Suitable for limited installation spaces without compromising performance.

Applications

    Automation Equipment: Ensures stable operation during high-precision movements.

    Industrial Machinery: Suitable for applications requiring high load capacity and precise control, such as robotic arms and material handling equipment.

    Food and Beverage Industry: Provides reliable performance in clean and oil-free environments. The SMC fittings can be trusted as for food safety.

Usage Instructions

Installation Steps:

Ensure the motor or rod side of the actuator is clean and free of dust.

Install the LZ-NT30 nut in the designated position and tighten it using appropriate tools. And make sure that other pneumatic fittings are also in the right position.

Check the installation for firmness to ensure there is no looseness.

Precautions:

Avoid applying excessive force during installation to prevent thread damage.

Regularly inspect the nut’s tightness in high-load or high-frequency use scenarios.

Frequently Asked Questions (FAQ):

1.Is customization available for LZ-NT30?

The LZ-NT30 is a standard component, and customization of pneumatic fittings is generally not supported. For special requirements, contact SMC’s technical support.

2.Are there restrictions on the installation direction for it?

The installation direction depends on the actuator’s design and application. Follow the device’s technical manual for proper installation.

3.What is the maintenance cycle for it?

It is recommended to perform maintenance checks quarterly, including inspecting the nut’s tightness and cleaning its surface.

4.Is it compatible with other brands?

The LZ-NT30 is designed specifically for SMC’s LZB series electric actuators, and compatibility with other brands cannot be guaranteed.

5.Is it suitable for harsh environments?

The LZ-NT30 is designed to meet IP67 protection standards, making it suitable for use in damp or dusty environments. However, it is not recommended for continuous contact with water, oil, or chemicals. For such environments, consult SMC’s technical support.

6.What is the lifespan of it?

The lifespan of LZ-NT30 depends on the operating environment and load conditions. It has a long service life under normal conditions. In high-vibration or high-load scenarios, increase the inspection frequency to ensure stability.

7.What is the thread specification of it?

The thread specification is M20 x 1.5.

8.How to handle a faulty it?

If the LZ-NT30 becomes loose or damaged, stop the machine for inspection and replacement. If unsure about the issue, contact SMC’s technical support.

9.Are there restrictions on the installation direction for it?

The installation direction depends on the actuator’s design and application. Follow the device’s technical manual to ensure the nut is installed correctly.

10.What is the material of it?

The LZ-NT30 is typically made from high-strength aluminum alloy or stainless steel, depending on the model.
