The SMC pneumatic solenoid valve AV4000-F04-5YZ-Q is a high-performance component designed for industrial automation systems. This pneumatic solenoid valve is ideal for applications requiring precise air supply control. It is compatible with SMC pneumatic fittings, offering seamless integration into various pneumatic control systems. The use of SMC pneumatic fittings ensures a secure connection between the valve and other components, contributing to the smooth operation of the entire system. SMC pneumatic fittings also provide enhanced durability and resistance to leakage, ensuring long-term reliability.
This product enables low-speed air supply and rapid exhaust, effectively protecting the pneumatic system from damage caused by sudden pressure changes. It also features energy-saving capabilities, high flow rates, and fast response times. The solenoid control valves in the system allow for precise operation of air distribution, ensuring optimal performance. Additionally, solenoid control valves offer excellent control over system pressure, preventing damage from sudden fluctuations.
Product Specifications
Main body size: 40 mm.
Thread type: Rc thread.
Connection port diameter: 1/2 inch.
Coil rated voltage: DC 24V.
Wiring method: D-type DIN socket with plug.
Operating pressure range: 0.2 to 1 MPa.
Pressure resistance: 1.5 MPa.
Ambient temperature: 0 to +60°C.
Flow characteristics: The C-value reaches 19.2 dm³/(s·bar), representing a maximum improvement of 2.3 times compared to the previous generation.
Product Features
Low-speed air supply and rapid exhaust: During startup, the SMC pneumatic solenoid valve provides air slowly, allowing the initial pressure in the pneumatic system to rise gradually. It also enables rapid exhaust when the air supply is cut off.
Energy-saving design: The valve consumes only 0.35W of power, and the airflow is zero when the main valve switches, further reducing energy consumption.
High flow and fast response: The improved flow characteristics allow the pneumatic solenoid valve to respond more quickly to system demands.
Safety features: Equipped with an LED indicator light and overvoltage protection circuit to enhance operational safety.
Easy installation and maintenance: The valve supports multiple installation options, and its size and thread design ensure compatibility with existing systems.
Manual operation: Non-locking push-button manual operation allows for manual control in emergency situations.
Applications
The AV4000-F04-5YZ-Q is widely used in automated machinery, pneumatic control systems, and other fields, especially in applications where precise control of startup speed is needed to protect the system or enhance comfort. Examples include:
Pneumatic slide control: Used in cleanrooms and industrial automation for pneumatic slides.
Automated equipment: Used in automotive, industrial, mining, and manufacturing sectors to control conveyors, robotic arms, and other devices.
Clean environments: Suitable for pneumatic systems in high-purity environments.
Maintenance Suggestions
Regular Inspection:
Check the device for any damage or abnormalities and ensure there are no leaks.
Clean the device surface and heat sinks to prevent dust accumulation.
Electrical Connections:
Ensure electrical connections are secure to avoid malfunctions due to poor contact.
When reconnecting electrical lines after maintenance, verify that the connections are correct.
Pneumatic System Maintenance:
Clean the pipes before installation to prevent contaminants from entering the system.
Regularly inspect pneumatic connections to ensure there are no leaks.
Safe Operation:
Ensure the device is powered off and the system pressure is released before maintenance or manual operation.
Confirm that the surrounding environment is safe when performing manual operations.
Indicator Light Function
The AV4000-F04-5YZ-Q is equipped with an LED indicator light to display the device's operating status, such as power and faults. The main functions of the indicator light include:
Status indication: Shows whether the device is operating normally, helping operators quickly assess its condition.
Troubleshooting: Allows for quick identification and diagnosis of faults through the indicator light status.
Operational guidance: Provides important prompts during device commissioning and maintenance.
Common Questions and Answers (FAQ)
How to ensure the soft-start valve's low-speed air supply function is working properly?
Check that the power supply voltage is stable and meets the device requirements.
Calibrate the startup speed and pressure parameters of the device.
Ensure the pneumatic connections are correct and leak-free.
How does the energy-saving feature of AV4000-F04-5YZ-Q work?
The device consumes only 0.35W of power, and the airflow is zero when the main valve switches.
The optimized flow characteristics further reduce energy consumption.
How to prevent electromagnetic interference with the device?
Use shielded cables and ensure the shielding layer is properly grounded.
Avoid placing signal lines close to power lines.
What is the manual operation method of AV4000-F04-5YZ-Q?
The device features a non-locking push-button manual operation for emergency control.
Ensure the device is powered off and the system pressure is released before manual operation.
How to extend the device's service life?
Regularly clean the device surface and heat sinks.
Avoid using the device in high-temperature, high-humidity, or strong electromagnetic interference environments.
Regularly inspect pneumatic and electrical connections.
Why is the flow characteristic of AV4000-F04-5YZ-Q better than the previous generation?
The flow characteristic has improved by up to 2.3 times, with a C-value of 19.2 dm³/(s·bar), allowing faster response to system demands.
How does the overvoltage protection function work?
The device has an integrated overvoltage protection circuit that automatically cuts off the power supply when the voltage is abnormal.
Ensure electrical connections are correct during maintenance.
How to choose the right installation location?
Select a well-ventilated environment free of dust and corrosive gases.
Ensure there is sufficient space around the device for heat dissipation.
What is the maximum operating pressure of AV4000-F04-5YZ-Q?
The maximum operating pressure of the device is 1.0 MPa.
How does the LED indicator light assist operators?
The LED indicator light displays the device's operating status, helping operators quickly determine if it is functioning normally.
During troubleshooting, the indicator light provides important prompts.
