The T0403W-20 is nylon tubing of SMC Corporation's T-Series. It is specifically designed for pneumatic and fluid transfer applications. The pipe is widely used for its high-pressure resistance, excellent flexibility, and superior chemical stability. This product is suitable for general pneumatic tubing, capable of withstanding high working pressures and offering a wide range of temperature adaptability.
Product Specifications
Dimensions: Outer diameter of 4 mm and inner diameter of 3 mm.
Material: Nylon 12, which provides excellent wear resistance and chemical resistance.
Color: White.
Length: Each roll is 20 meters long.
Working Pressure: Maximum operating pressure of 1.5 MPa at 20°C.
Working Temperature: Air: -40°C to +100°C; Water: 0°C to +70°C (non-freezing).
Minimum Bending Radius: 20 mm.
Product Features
High-Pressure Resistance: Capable of withstanding pressures up to 1.5 MPa at 20°C, making it suitable for various high-pressure fluid transfer environments.
Temperature Resistance: Suitable for a wide temperature range to ensure stability in extreme conditions.
Flexibility: The nylon material offers excellent flexibility, making it easy to install and configure.
Easy Connection: Compatible with various fittings, including quick-change, push-in, and compression fittings.
Applications
The T0403W-20 nylon tubing is widely used in the following areas:
Automation Equipment: For connecting pneumatic components to ensure efficient equipment operation.
Hydraulic and Pneumatic Systems: As a reliable transfer pipe for high-pressure environments.
Chemical and Petroleum Industries: For transferring media such as air, water, and turbine oil.
Installation Instructions
Environment: Choose a dust-free, non-corrosive gas, and low electromagnetic interference environment to ensure proper heat dissipation of the equipment.
Connection: Ensure correct piping connections to prevent leaks. Use appropriate fittings to ensure secure connections.
Maintenance: Regularly inspect the tubing for damage or leaks, and clean dust and impurities to ensure normal system operation.
Precautions
Pressure Limit: Ensure that the working pressure does not exceed the maximum allowable pressure of the tubing.
Temperature Limit: Avoid using in extreme temperatures, especially for water media, to prevent freezing.
Chemical Compatibility: When transferring chemical media, confirm compatibility with nylon material.
Frequently Asked Questions and Answers
What is the maximum working pressure of T0403W-20?
Answer: The maximum working pressure of T0403W-20 is 1.5 MPa at 20°C. The maximum working pressure decreases at higher temperatures.
Explanation: The working pressure of nylon tubing decreases with increasing temperature, so special attention is needed when using it in high-temperature environments.
Recommendation: In practical applications, select the appropriate working pressure based on the ambient temperature to ensure safety and reliability.
What is the temperature range of this SMC nylon tubing product?
Answer: The working temperature range of T0403W-20 is -40°C to +100°C for air, and 0°C to +70°C for water.
Explanation: Although nylon tubing has a wide temperature range, it is important to note the temperature limits for water media to avoid freezing or overheating.
Recommendation: When using in low or high-temperature environments, ensure the tubing's temperature adaptability and consider insulation or cooling measures if necessary.
Is the product suitable for transferring chemical media?
Answer: T0403W-20 is suitable for transferring media such as air, water, and turbine oil.
Explanation: Nylon 12 material has excellent chemical resistance and can withstand corrosion from various chemical media.
Recommendation: When transferring other chemical media, verify compatibility with nylon material in advance to avoid potential chemical reactions.
How to choose the right fittings for it?
Answer: T0403W-20 is compatible with various fittings, including quick-change, push-in, and compression fittings.
Explanation: Different fitting types are suitable for different applications, and choosing the right fitting ensures secure and leak-free connections.
Recommendation: Select the appropriate fitting type based on actual application needs and ensure compatibility between the fitting and tubing.
What is the minimum bending radius of this pneumatic tubing product?
Answer: The minimum bending radius of T0403W-20 is 20 mm.
