The SICK TR110-SRUSA00 is a high-performance safety door switch designed for industrial automation. As part of the SICK interlock switch family, it ensures non-contact safety switch functionality, providing fail-safe operation in high-risk environments. Engineered to comply with EN ISO 14119 standards, it features a mechanical-electrical design with positive opening contacts, making it an essential safety solution for equipment interlocking in industrial settings.

Non-Contact Safety Door Switch SICK TR110-SRUSA00 | Interlock System For Cobot Applications

Product Specifications

Electrical Specifications:

Rated operating current: 3A (240V AC) / 2A (24V DC).

Rated insulation voltage: 240V.

Rated impulse withstand voltage: 2500V AC.

Short-circuit protection: T10/10A.

Switching voltage: ≥5V DC.

Switching current: 5mA (5V DC).

Mechanical Specifications:

Weight: 0.08 kg.

Housing material: Glass fiber-reinforced thermoplastic.

Mechanical service life: 1×10⁶ switching operations.

Environmental Specifications:

Housing protection rating: IP67.

Operating temperature range: -20°C to +80°C.

Storage temperature range: -20°C to +80°C.

Other Features:

Positive opening of normally closed contacts: 2.

Holding force: ≤6N.

Operating frequency: ≤7200 cycles per hour.

Activation direction: 5.

Approach speed: ≤10m/min.

Product Features

The i12-SA203 features the following notable characteristics:

High Safety: Compliant with EN ISO 14119 standard, it uses low encoding levels to ensure greater safety in case of errors.

Durability: As a high-quality interlock switch, it offers a mechanical service life of 1×10⁶ switching operations, ensuring long-term reliability in demanding environments.

High Protection Rating: The IP67 housing protection rating allows it to operate stably in harsh environments.

Flexible Connection: It supports cable entry with a conductor cross-section of ≤1.5mm².

Application Scenarios

The SICK TR110-SRUSA00 safety door switch is suitable for a variety of industrial automation scenarios, including but not limited to:

Mechanical Protection: The interlock switch ensures fail-safe operation for safety doors and emergency stop switches, preventing unauthorized access to hazardous areas.

Logistics and Warehousing: For safety protection and equipment control in automated warehouses.

Food Processing: Ensures operator safety by providing safety control in food processing equipment.

Automotive Manufacturing: Used in safety doors and emergency stop devices on automotive production lines.

Usage Instructions

Installation and Wiring

Installation Environment: The SICK TR110-SRUSA00 safety door switch should be installed in a dust-free, non-corrosive environment with minimal electromagnetic interference to ensure optimal performance.

Wiring Requirements: Follow the wiring diagram in the product manual strictly to ensure correct connections for power, signal, and control lines.

Grounding Protection: Ensure proper grounding of the device in accordance with national and local electrical safety standards.

Parameter Settings

Electrical Parameters: When configuring this non-contact safety switch, adjust the switching current and voltage based on the specific safety control system requirements.

Safety Functions: Ensure that safety-related logic units are connected to the device for fault detection.

Maintenance and Inspection

Regular Inspection: Check for housing damage, secure connections, and clean dust from heat sinks.

Parameter Verification: Regularly verify electrical parameters to ensure normal device operation.

Fault Diagnosis: In case of a malfunction, inspect the non-contact safety switch for error codes and follow standard troubleshooting procedures.

Precautions

Environmental Conditions: Avoid using the product in high-temperature, high-humidity, or strong electromagnetic interference environments.

Power Requirements: Ensure stable power voltage to prevent damage to the device from voltage fluctuations.

Safe Operation: The interlock switch is designed to prevent unintended access to hazardous machinery, ensuring operator safety by eliminating the risk of contact with live components.

Frequently Asked Questions and Answers

Does the SICK TR110-SRUSA00 safety door switch require a separate purchase of the actuating element?

Yes, the actuating element for the i12-SA203 needs to be purchased separately. For details, refer to the "Accessories" section in the product manual.

What is the protection rating of the i12-SA203 interlock switch?

The i12-SA203 has an IP67 housing protection rating, which effectively protects against dust and water ingress.

What is the operating temperature range of the i12-SA203?

The operating temperature range of the i12-SA203 is -20°C to +80°C, allowing it to operate stably in various harsh industrial environments, whether in low or high-temperature conditions.

Does the i12-SA203 support cable connections?

Yes, the i12-SA203 supports cable connections with a maximum conductor cross-section of 1.5 mm². This connection method offers flexible installation options to meet different industrial site requirements.

What is the operating frequency of the i12-SA203?

The i12-SA203 can achieve an operating frequency of up to 7200 cycles per hour, making it suitable for high-frequency applications such as emergency stop switches or safety door controls in automated production lines.

What is the holding force of the i12-SA203?

The holding force of the i12-SA203 is ≤6N, meaning that operators can easily activate the safety switch with low holding force while ensuring its stability during normal operation.

What is the activation direction of the i12-SA203?

The activation direction of the i12-SA203 is 5, indicating specific directional limitations. When installing and using the device, follow the instructions in the product manual to ensure the correct activation direction to prevent misoperation or equipment damage.

Is the i12-SA203 compliant with international safety standards?

Yes, the i12-SA203 is compliant with the EN ISO 14119 standard, which is an international standard for mechanical safety switches. This ensures that the device meets the highest safety requirements in design and operation, making it a high-quality safety switch that adheres to international safety standards.

What is the mechanical service life of the i12-SA203?

The mechanical service life of the i12-SA203 is 1×10⁶ switching operations. This means that under normal operating conditions, the safety switch can withstand up to one million switching operations, demonstrating high durability and meeting the demands of long-term industrial applications.

What is the housing material of the i12-SA203?

The housing of the i12-SA203 is made of glass fiber-reinforced thermoplastic. This material not only offers high strength and durability but also provides excellent insulation properties, as well as corrosion and impact resistance, ensuring stable operation in harsh industrial environments.
