The SICK PAC50-BGA is a high-performance pressure level sensor and smart sensor designed specifically for industrial automation and pneumatic applications. This versatile pressure level sensor offers high-precision measurement, a dual-color LCD display, flexible output signal configuration, and a robust housing. It is suitable for various industrial scenarios, including compressed air monitoring, vacuum measurement, and leak detection.
Product Specifications
Measurement Range: –1 bar to +1 bar.
Overload Protection: Up to 5 bar.
Output Signal: Optional 4 mA to 20 mA or 0 V to 10 V analog output; supports PNP/NPN push-pull digital output.
Display: 4-digit LCD display with green/red LED backlight, rotatable by 180°, and switchable pressure units (bar, MPa, kPa, psi, inHg).
Supply Voltage: 17 V DC to 30 V DC.
Housing Protection Class: IP65 and IP67.
Operating Temperature: 0°C to +60°C.
Storage Temperature: –20°C to +80°C.
Relative Humidity: ≤90% RH.
Product Features
High-Precision Measurement: Nonlinearity ≤ ±0.5%, accuracy ≤ ±1.5% of range.
Dual-Color Display: Green/red backlight with a rotatable display for easy remote monitoring.
Flexible Mounting Options: Rail mounting, wall mounting, or installation in control panels.
Robust Design: Made of polycarbonate material with high protection classes, suitable for harsh industrial environments.
Quick Diagnostics: Fault diagnosis output for easy troubleshooting.
Application Scenarios
Compressed Air Monitoring: For pressure monitoring in machines or equipment using a pressure level sensor.
Vacuum Measurement: Suitable for vacuum monitoring in handling and robotic applications with smart sensors. These smart sensors ensure that the system remains efficient by providing precise and reliable readings.
Leak Detection: Effective for detecting leaks in closed compressed air systems with switches sensors. Switches sensors help in identifying any irregularities, making it a reliable option for continuous system monitoring. Additionally, switches sensors offer precise switching functionality to improve leak detection.
Industrial Automation: Widely used in pneumatic systems, robotics, and other applications requiring precise pressure level sensor control. Smart sensors play a key role in streamlining automation processes, providing accurate feedback and enabling seamless system integration.
Installation and Usage Instructions
Installation and Wiring
Installation Environment: Choose a clean, non-corrosive, well-ventilated area. Avoid high temperatures, humidity, and strong electromagnetic interference.
Wiring Requirements: Use an M12 circular connector to ensure correct connections for power and signal lines.
Grounding Protection: Ensure proper grounding to comply with electrical safety standards.
Parameter Settings
Measurement Range Selection: Choose the appropriate range based on application needs.
Output Signal Configuration: Set analog or digital output through the device menu.
Zero Adjustment: Up to ±5% of range for fine-tuning.
Maintenance and Inspection
Regular Checks: Inspect the housing for damage and clean dust from heat sinks and fans.
Parameter Verification: Periodically verify sensor settings to ensure they match application requirements.
Precautions
Environmental Conditions: Avoid using in high-temperature, high-humidity, or strong electromagnetic interference environments.
Power Supply Requirements: Ensure stable supply voltage to prevent damage from voltage fluctuations.
Safe Operation: Avoid contact with live parts during operation.
Frequently Asked Questions (FAQ)
What is the measurement range of the PAC50-BGA?
The PAC50-BGA has a measurement range of –1 bar to +1 bar, suitable for low-pressure and vacuum environments. It also features overload protection up to 5 bar.
How to configure the output signal for the pressure level sensor?
The pressure level sensor supports multiple output configurations, including 4 mA to 20 mA and 0 V to 10 V analog outputs, as well as PNP/NPN push-pull digital outputs. Users can configure the output through the device menu.
What are the features of the display on this smart sensor?
The smart sensor features a 4-digit LCD display with green/red backlighting, rotatable by 180° for easy viewing from different angles. Users can switch between pressure units like bar, MPa, kPa, psi, and inHg.
How to ensure the measurement accuracy of this sensor?
The pressure level sensor offers nonlinearity of ±0.5% and accuracy of ±1.5% of range. Users can further optimize accuracy through zero adjustment (up to ±5% of range).
What is the protection class of the housing for the PAC50-BGA sensor?
The PAC50-BGA features a housing protection class of IP65 and IP67, effectively preventing dust and water ingress, making it suitable for harsh industrial environments.
What are the mounting options for this smart sensor?
This smart sensor supports multiple mounting options, including rail mounting, wall mounting, or installation in control panels. It also has G ¼ internal thread connections for easy integration.
What are the power supply requirements for the PAC50-BGA sensor?
The PAC50-BGA operates on a supply voltage range of 17 V DC to 30 V DC. Ensure stable voltage to prevent sensor damage. The device consumes a maximum current of 40 mA (when L+=24 V DC).
How to perform fault diagnosis with the PAC50-BGA sensor?
The PAC50-BGA supports fault diagnosis output. Users can set one of the digital outputs as a diagnostic output. When a fault occurs, users can view fault codes on the display and troubleshoot according to the manual.
Does this smart sensor support IO-Link interface?
While the PAC50-BGA does not support IO-Link, other models in the series (such as PAC50-BGC or PAC50-BGD) do. IO-Link enables fast parameter configuration and device replacement, reducing downtime.
What is the lifespan of the pressure level sensor?
The pressure level sensor has a Mean Time To Failure (MTTF) of 261.31 years. Its robust polycarbonate housing and high-performance electronics ensure long-term stability in harsh environments.
