SMC pneumatic solenoid valve AV3000-03-5DZ-Q is designed for efficient control of air flow in pneumatic systems. This SMC pneumatic solenoid valve works seamlessly with pneumatic fittings, ensuring optimal performance and reliability in industrial applications. It provides precise pneumatic control and is widely used in applications requiring slow start-up and rapid exhaust.
Product Specifications
Main body size: 30mm.
Thread type: Rc thread.
Connection port diameter: 3/8 inch.
Coil rated voltage: DC 24V.
Wire connection method: Type D DIN socket with plug.
LED and overvoltage protection circuit: Equipped with indicator light and overvoltage protection.
Manual operation: Locking type.
Flow direction: Right to Left.
Operating pressure range: 0.2 to 1 MPa.
Ambient temperature: 0 to +60°C.
Product Features
Slow Start and Rapid Exhaust: This air solenoid valve provides low-speed air supply and rapid exhaust after air supply is cut off, making it suitable for equipment that requires smooth start-up and quick stop. The air solenoid valve allows for efficient control in these types of applications, ensuring smooth operation and quick response times. This feature is essential for machines that rely on precise air control, and it enhances the overall efficiency of the system.
The air solenoid valve is designed to operate with pneumatic fittings to ensure optimal performance in various industrial applications. It is especially ideal for processes that require controlled air flow, and it integrates seamlessly with systems needing a smooth start and fast stop.
High Reliability Design: Utilizes advanced sensorless vector control technology and enhanced reliability design to meet various pneumatic transmission application requirements.
Easy Operation and Maintenance: Equipped with intuitive LED indicator lights and overvoltage protection circuits, making it convenient for users to monitor equipment status and perform maintenance.
Flexible Installation: Supports Type D DIN socket connection, making installation simple and suitable for compact industrial environments.
Application Scenarios
Industrial Automation Equipment: Controls conveyors, robotic arms, and other devices on production lines to achieve smooth start-up and stop.
Pneumatic Slides and Mechanisms: Suitable for slides, clamps, and other devices requiring precise pneumatic control, along with high-quality pneumatic fittings for optimal connections.
Packaging and Logistics Equipment: Used in packaging machines and logistics conveyance systems, integrating pneumatic fittings to enhance equipment efficiency with slow start-up and rapid exhaust.
Food Processing and Pharmaceutical Equipment: Provides reliable pneumatic control in clean and sanitary environments, with carefully selected pneumatic fittings for consistent performance.
Installation and Usage Instructions
Installation Environment:
Choose a dust-free, non-corrosive gas, and low electromagnetic interference environment.
Ensure proper ventilation and avoid installing in high-temperature, high-humidity, or poorly ventilated areas.
Wiring Requirements:
Follow the product manual strictly for correct connections of power, signal, and control lines.
Use shielded cables and ensure proper grounding to minimize electromagnetic interference.
Parameter Settings:
Adjust operating pressure, start-up speed, and other parameters based on actual application needs.
Regularly verify parameter settings to ensure stable equipment operation.
Maintenance and Inspection
Regularly clean the device surface and heat sinks to ensure proper cooling system operation.
Check for loose connections and ensure electrical connections are secure.
Precautions
Environmental Conditions:
Avoid using in high-temperature, high-humidity, or strong electromagnetic interference environments to prevent performance degradation and reduced lifespan.
In harsh environments, consider installing protective enclosures or dust filters.
Power Requirements:
Ensure stable power voltage to prevent damage from voltage fluctuations.
Wait for a period before re-powering the device after shutdown.
Safe Operation:
Avoid contact with live parts during operation.
Disconnect power and ensure capacitor discharge is complete before maintenance or inspection.
Frequently Asked Questions (FAQ)
How to Ensure the Slow-Start Function Works Properly?
Check power voltage: Ensure stable power voltage that meets device requirements.
Calibrate parameter settings: Adjust start-up speed and pressure parameters based on actual application needs.
Inspect air circuit connections: Ensure correct connections with no leaks.
What is the Cooling Method for the Solenoid Valve?
Cooling method: The device uses natural cooling.
Installation requirements: Ensure sufficient space around the device for air circulation and avoid installing in enclosed environments.
Maintenance: Regularly clean the device surface and heat sinks to prevent dust accumulation that may affect cooling efficiency.
How to Avoid Electromagnetic Interference with the SMC pneumatic solenoid valve?
Use shielded cables: Ensure proper grounding of the shielding layer during wiring.
Separate signal and power lines: Keep signal and power lines apart to reduce electromagnetic interference.
Proper grounding: Ensure the device is properly grounded in accordance with electrical safety standards.
What is the Maintenance Cycle for AV3000-03-5DZ-Q?
Regular appearance inspection: Check the device appearance monthly for any damage or abnormalities.
Clean heat sinks: Clean the heat sinks and device surface quarterly to ensure proper cooling.
Verify parameters: Calibrate device parameters semi-annually to ensure settings match actual requirements.
How to Choose the Right SMC pneumatic solenoid valve?
Select based on application: Choose the appropriate connection port size, voltage, and control method based on actual needs.
Consider environmental conditions: Select a SMC pneumatic solenoid valve with the appropriate protection rating based on the installation environment.
Consult technical support: If unsure, consult SMC technical support for guidance.
What is the Manual Operation Method for the SMC pneumatic solenoid valve?
Locking operation: The valve uses a locking manual operation method that requires tools.
Operation precautions: Ensure the device is powered off during manual operation.
Function description: Manual operation is used for device control during commissioning or emergency situations.
How to Resolve Issues with the Solenoid Valve Not Starting Properly?
Check power connections: Ensure normal power voltage and correct connections.
Check air circuit pressure: Confirm the air source pressure is within the device's operating range.
Check device fault codes: Diagnose and resolve issues based on the displayed fault codes.
How Does the Overvoltage Protection Function Work on AV3000-03-5DZ-Q?
Protection mechanism: The device has an overvoltage protection circuit that automatically cuts off power in case of abnormal voltage.
Check power quality: Regularly verify the stability of the power voltage to avoid fluctuations.
Maintenance recommendations: Periodically calibrate the protection function to ensure it operates correctly.
How to Extend the Lifespan of the Solenoid Valve?
Keep the device clean: Regularly clean the device surface and heat sinks to prevent dust accumulation.
Avoid harsh environments: Do not use in high-temperature, high-humidity, or strong electromagnetic interference environments.
Perform regular maintenance: Follow the device manual for regular maintenance and parameter calibration.
What is the Function of the Indicator Light on the Solenoid Valve?
Status indication: The LED indicator light shows the device's operating status, such as power and faults.
Troubleshooting: Quickly diagnose whether the device is working normally through the indicator light status.
Operational guidance: The indicator light provides important operational guidance during device commissioning and maintenance.
