The SMC VM130-01-30BA is a 2/3-way machine control valve from the SMC VM100 series, designed to meet the demanding needs of pneumatic air cylinder systems and pneumatic rotary applications.
This valve is especially suitable for air control solenoid valves, offering a lightweight and compact solution for precise control in SMC pneumatics USA systems. The SMC pneumatics product delivers excellent performance across various industries, featuring a pressure range of -100kPa to 1MPa, and supporting various mounting methods, including bracket, side, bottom, and panel mounting.
Product Specifications
Number of Ports: 3 ports
Piping Direction and Pushrod Length: Side piping, long pushrod
Main Body Options: Side mounting available
Connection Port Size: Rc1/8
Actuator Type: Button type (mushroom head)
Actuator Identifier: Button knob color: Black
Indicator Light Identifier: None
Bracket Options: None
Custom Specification: Standard series
Pneumatic Air Cylinder Systems: Ideal for actuating elements in pneumatic air cylinders, such as stop valves and speed control valves, enabling precise control.
VM Valve Size: 100
Maximum Operating Pressure: 0.7 MPa
Minimum Operating Pressure: -0.01 MPa
Ambient Temperature: -5°C to 60°C
Fluid Type: Air
Lubrication: Non-lubricated
C Value 1(P)⇒2(A): 0.6 dm³/(s·bar)
b Value 1(P)⇒2(A): 0.2
Cv Value 1(P)⇒2(A): 0.11
C Value 2(A)⇒3(R): 0.5 dm³/(s·bar)
b Value 2(A)⇒3(R): 0.15
Cv Value 2(A)⇒3(R): 0.1
Product Features
Lightweight Design: The SMC VM130-01-30BA valve weighs only 60g, making it easy to install and maintain in various pneumatic air cylinder applications.
Multiple Installation Methods: It offers flexibility for installation in SMC pneumatics systems with bracket, bottom, side, and panel mounting options.
Vacuum Environment Compatibility:This valve operates within a pressure range of -100kPa to 1MPa, making it perfect for pneumatic rotary applications.
Mini Indicator Light: Ensures air presence for smoother operation and troubleshooting in pneumatic air cylinder systems.
Air Operated Cylinders: The SMC VM130-01-30BA valve is perfectly suited for air control solenoid valves, providing smooth and reliable control for various pneumatic applications.
Application Scenarios
Pneumatic Control Systems:Ideal for actuating elements in pneumatic air cylinder systems, such as stop valves and speed control valves, enabling precise control.
Pneumatic-Hydraulic Circuit Control: This valve can also control the movement of pneumatic piston cylinders, offering flexibility for both pneumatic and hydraulic circuits.
SMC Pneumatics USA: Widely used across the USA, the SMC VM130-01-30BA valve is perfect for integration into SMC pneumatics systems, offering versatility for industrial applications, including air control solenoid valves.
Usage Instructions
Read and Understand the Manual: Ensure safety during installation and use by thoroughly reading and understanding the product manual.
Ensure Sufficient Maintenance Space: Make sure the installation location has enough space for maintenance and inspection.
Tighten Threads with Recommended Torque: Secure the connections using the recommended torque to ensure a firm connection in SMC pneumatics systems.
Function and Leak Checks: After installation and maintenance, connect the air source and power supply, and perform necessary function and leak checks to confirm correct installation.
Usage Precautions
Product Markings: Do not remove, peel off, or damage the warning and specification markings printed or affixed on the product. When painting, consult with the company to avoid the impact of organic solvents on resin material markings.
Tighten Threads with Recommended Torque: Strictly follow the recommended torque to tighten the threads to prevent leaks due to loose threads in pneumatic air cylinder systems.
Function and Leak Checks: Always perform function and leak checks after installation and maintenance to ensure correct installation.
Environmental Conditions
Low-Temperature Use: The product can be used at a minimum temperature of -5°C, but freezing must be avoided.
Product Markings: Do not remove, peel off, or damage the warning and specification markings printed or affixed on the product. When painting or performing other treatments, consult with the company to avoid the impact of organic solvents on resin material markings.
Common Questions and Answers
1.Can this product be used in SMC Pneumatics USA systems?
Answer: Yes, the VM130-01-30BA valve is compatible with SMC pneumatics USA systems, ensuring reliable and efficient control for air control solenoid valves and other pneumatic applications.
2.Is it suitable for air cylinder systems?
Answer: Yes, this valve is designed for optimal performance in pneumatic air cylinder systems, providing precise control and versatility for various pneumatic applications.
3.How to ensure correct installation?
Answer: Always tighten the threads with the recommended torque to ensure a secure connection. After installation and maintenance, connect the air source and power supply, and perform necessary function and leak checks. Follow the detailed steps in the product manual to ensure proper installation.
4.Can the markings on the product be removed?
Answer: No, the product’s warning and specification markings are crucial for ensuring proper usage and maintenance and should not be removed or damaged.
5.How to choose the right installation location?
Answer: Select an installation location with good ventilation, free from dust, and without corrosive gases. Ensure there’s enough space for routine maintenance and inspection.
6.How to perform routine maintenance?
Answer: Regularly inspect the valve for damage, clean the components, and check the operational parameters to ensure they match the system’s needs.
7.How to handle equipment failures?
Answer: When faults occur, check the fault code and refer to the troubleshooting guide in the manual. If the issue persists, contact the manufacturer for further assistance.
8.How to choose the right power and air sources?
Answer: Ensure that the power source is stable and that the air source is clean, dry, and has stable pressure to meet the equipment’s needs.
9.How to choose the right control mode?
Answer: Select the control mode based on application needs and configure it for optimal performance, especially in pneumatic air cylinder applications.
10.How to set the frequency setting channel?
Answer: The frequency setting can be configured through the inverter panel or external analog/digital signals, ensuring accuracy and stability for SMC pneumatics applications.
