the SMC VM430-01-08, an aluminum alloy component with a 1/8 inch Rc threaded connection from the SMC speed control valve series, is designed for durability, high repeatability, versatility, and ease of maintenance. When used for SMC actuators, this component operates with air as the working medium, within a pressure range of -100 kPa to 1.0 MPa, and a temperature range of -5°C to 60°C.
Product Specifications
Valve Body Size: 1/8 inch Rc threaded connection
Effective Cross-Sectional Area: 5.36 mm²
Maximum Flow Rate: 338.77 nl/min
Material: Aluminum alloy
Operating Pressure: 1 MPa
Temperature Range: -5°C to 60°C
Weight: Approximately 200 grams
Product Features
Durability: Built with robust design for long-term use.
High Repeatability: High operational precision and good repeatability.
Versatility: Suitable for various pneumatic control systems.
Easy Maintenance: Simple design for easy maintenance and part replacement.
Working Medium: Air
Pressure Range: -100 kPa to 1.0 MPa
Temperature Range: -5°C to 60°C
Applications
Pneumatic Control Systems: Used as stop valves and speed control valves for actuators, enabling intermediate stop and jogging control.
Pneumatic-Hydraulic Circuit Control: Controls the on-off of pneumatic-hydraulic circuits.
General Industrial Machinery: Suitable for various pneumatic control circuits, such as machine tools and automated equipment.
Usage Instructions
Installation and Wiring
Installation Environment: Choose a well-ventilated, dust-free, and non-corrosive gas environment for installation. Avoid high temperature, high humidity, or strong electromagnetic interference areas.
Installation Method: To operate smoothly for actuators, ensure the SMC speed control valve is installed vertically for easy operation and maintenance. Use appropriate fixing methods to prevent vibration effects.
Connections: Use Rc 1/8 threaded connections, ensuring a secure and leak-free connection.
Parameter Settings
Basic Parameter Settings: Include working pressure and temperature, set according to actual application needs.
Advanced Function Configuration: Such as multi-speed control, configure according to specific application scenarios for more complex control functions.
Maintenance and Inspection
Regular Inspection: Check the SMC speed control valve's appearance for damage and aging seals. Regularly clean dust from the valve.
Parameter Verification: To operate smoothly for actuators, regularly verify the SMC speed control valve's parameter settings to ensure they match the actual application needs.
Fault Diagnosis: When a fault occurs, promptly check the fault code and follow the troubleshooting guide in the manual for diagnosis and resolution.
Precautions
Environmental Conditions: Avoid using the SMC 1/8 fitting in high temperature, high humidity, or strong electromagnetic interference environments to prevent performance and lifespan issues.
Power Requirements: Ensure stable air pressure to avoid damage to the valve from pressure fluctuations.
Safe Operation: Avoid contact with live parts during operation to ensure operator safety. When performing maintenance and inspection, disconnect the air supply and wait for system depressurization.
