peculiarity
Four gigabit POE ports and one gigabit POE port are supported
Support IEEE802.3at standard, compatible with IEEE802.3af power receiving Device (PD)
Single port output power up to 30W
Automatic detection of PD devices
Automatic detection and identification of standard PoE receiving equipment, intelligent power supply, will not burn non-standard PoE receiving equipment or ordinary equipment
Supports the priority of port power supply to ensure continuous power supply to key nodes on the network
Supports IEEE802.3x full duplex flow control and Backpressure half duplex flow control
Panel indicators View the working status and help fault analysis
Perfect security mechanism
Intelligent identification of line speed forwarding
Data exchange adopts store-and-forward mode
Operating temperature: 0°C ~ 40 °C
argument
Functional characteristics
Port specification
Four 10/100/1000Mbps adaptive RJ45 ports and one up-connected RJ45 Gigabit port
Switching mode
store-and-forward
PoE function
PoE standard
IEEE802.3 af/ats
PoE port
1-4
Maximum power supply for a port
30W
Maximum power supply of the whole machine
40W
Universal parameter
Dimensions (width × height × depth)
140mm x 76.7 mm x 27.2mm
Operating temperature
0 °C - 40 °C
Working humidity
10%-90% (non-condensing)
Storage temperature
-40°C - 75 °C
Storage humidity
5%-90% (non-condensing)
Installation mode
desktop
Power supply mode
100-240V AC 50/60Hz
fan
fanless
Overall power consumption
≤45 W
