Product characteristics
Compatible with ONVIF, RTSP standards of many mainstream manufacturers of network cameras;
Supports access to H.265, Smart265, H.264, and Smart264 video coding streams.
Support up to 4 million pixel HD network video preview, storage and playback;
Support 6-way 1080P decoding, can be fully connected to 4 million pixel HD IPC;
Support HDMI and VGA same-origin HD output, HDMI and VGA both support HD 1080P output;
Supports one SATA port and a maximum of 8T hard disks.
Comes with 4 /8 PoE network ports, can be directly connected to the PoE camera power supply, plug and play, fast picture;
Equipped with front-end intelligent IPC, supporting people and vehicles video marking and quick playback functions, greatly improving video playback and retrieval efficiency;
Supports centralized management of IP devices, including one-click addition, parameter configuration, batch upgrade, and import/export of IP devices.
Support fluorite cloud service, remote preview/playback/configuration of mobile phone can be achieved through Haikang Internet APP;
Product parameter
System parameter
Number of video access channels
Four ways
Network input bandwidth
40Mbps
Network output bandwidth
60Mbps
Video resolution
4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Video parameter
Video output
1 HDMI, 1 VGA
HDMI output
1 channel, same origin as VGA
Resolution: 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
VGA output
1 channel, resolution: 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
Video decoding format
H.265; Smart265; H.264; Smart264
Decoding capability
6*1080P
Synchronous playback
4
Hard disk management
Panel position
One SATA port
Single disk capacity
Supports a maximum of 8TB
Video management
Video/capture mode
Timing video, event video, motion detection video, alarm video, dynamic measurement or alarm video, dynamic measurement and alarm video
Playback mode
Instant replay, general replay, event replay, tag replay, external file replay
Backup mode
Routine backup and event backup
Network management
Network protocol
UPnP (Plug and play), NTP (Network calibration), SADP (Device network search), DHCP (automatic IP address acquisition)
External interface
Network interface
1, RJ45 10M/100M adaptive Ethernet port
USB interface
2 USB 2.0 (rear)
PoE
POE interface
4
POE standard
IEEE 802.3af/at
POE output power
≤36W
General norm
Power supply specification
DC 48V 50W (External adapter)
Power consumption (excluding hard disk)
≤10W
Operating temperature
- 10 ℃ - + 55 ℃
Working humidity
10% -- 90%
chassis
1U 260 chassis
dimension
265mm (W) x 225mm (D) x 48mm (H)
Weight (excluding hard disk)
≤1Kg
other
Infrared remote control
nonsupport
