Product characteristics
Support red mouth guarantee
Support 8-core power supply
Supports transmission up to 250 m
Supports PoE output power management
Line speed forwarding, non-blocking design
Store-and-forward switching mode
Rugged, high-strength metal housing
Fanless design, high reliability
Product parameter
Functional characteristics
Switching mode: store-and-forward
Web standards: IEEE802.3, IEEE802.3 u, IEEE802.3 x
PoE function
Hi-PoE port: None
PoE standard: IEEE802.3af/IEEE802.3at
Power supply core: 8-core power supply
PoE ports: Ports 1 to 8
Port maximum power supply: 30 W
Maximum power supply: 60 W
PoE distance: Port 1 -- 8
Performance parameter
Exchange capacity: 1.8Gbps
Packet forwarding rate: 1.339 Mpps
MAC address capacity: 2 K
Universal parameter
Ports: 8 100 Mbit PoE ports and 1 100 Mbit POE port
Long-distance transmission ports: Port 1 -- 8
High priority ports: Ports 1 to 2
Weight: 0.35 kg
Fan: None
Dimensions (length × height × depth) : 170 mm × 27.6 mm × 93.1 mm
Operating temperature: 0 °C -- 40 °C
Working humidity: 5%-95% (no condensation)
Storage temperature: -40 °C - 85 °C
Storage humidity: 5% -- 95% (no condensation)
Power supply: DC 48 V
Installation mode: Desktop
Power consumption: 65W
Surge protection: 6 kV
