The SMC MKB12-10RZ rotary clamping cylinders are smc cylinders with magnetic valves and regulator valves in the MK series, featuring enhanced allowable inertia torque,multi-directional magnetic switch installation with magnetic valves, compatible mounting dimensions.
and updates to the new MK series. It is widely used in applications that require precise control and stability, such as electronics and light assembly, and as core components in grasping technology.
Product Details
Product Specifications
1. Cylinder diameter: 12mm, providing suitable clamping force and stability.
2. Clamping stroke: 10mm, suitable for short-stroke application requirements.
3. Rotation direction: Right rotation, meeting the clamping needs of specific directions.
4. Port thread type: M thread, adapting to different interface requirements.
5. Clamping force: 40 N, ensuring sufficient force in clamping operations.
6. Operating fluid: Air, adaptable to environmental temperatures of -10 to 60°C.
7. Guaranteed pressure resistance: 1.5 MPa, providing high pressure resistance.
8. Rotation stroke: 7.5mm.
9. Working pressure: 0.1-1.0 MPa.
10. Working temperature: -10-70°C.
Product Features
1. Enhanced allowable inertia torque: The allowable inertia torque of the MKB12-10RZ has been increased threefold, the same as the heavy-duty MK2 series, meaning it can maintain stable performance even under high load conditions.
2. Multi-directional magnetic switch installation: The smc cylinders can install magnetic valves which switches from four directions, providing greater flexibility and facilitating the integration of automated control systems.
3. Compatible mounting dimensions: The mounting dimensions of the MKB12-10RZ are the same as the MK series, making it convenient for users to replace and upgrade existing equipment without changing the mounting structure.
4. New MK series update: The MK series and MK2 series have been merged and updated to the new MK series, providing a more unified product line and simplifying product selection and maintenance work.
Application Scenarios The MKB12-10RZ model smc cylinders is suitable for applications that require precise control and stability, such as electronics and light assembly, and as core components in grasping technology. Its compact design and high-performance features make it an ideal choice in the field of industrial automation, especially in clean room environments.
Usage Instructions
Installation and Wiring
1. Installation environment: Choose a well-ventilated, dust-free, and non-corrosive gas environment for installation. Avoid installing the smc cylinders in high-temperature, high-humidity, or strong electromagnetic interference environments.
2. Installation method: Ensure the smc cylinders is installed vertically for proper heat dissipation. Use appropriate fixing methods during installation to prevent equipment damage from vibrations.
3. Power connection: When connecting the power supply, ensure the power cable specifications meet the requirements and pay attention to the correct phase sequence. Also, ensure the equipment is properly grounded.
Parameter Settings
1. Basic parameter settings: Include motor parameters, control methods, frequency ranges, etc., and set them reasonably according to actual application requirements. For example, for applications requiring high-precision control, you can choose the flux vector control mode.
2. Advanced function configuration: Such as PID control, multi-speed control, etc., configure them according to specific application scenarios to achieve more complex control functions.
Maintenance and Inspection
1. Regular inspection: Check the appearance of the smc cylinders for damage, dust on the heat sink, and normal operation of the fan. Regularly clean the dust on the heat sink and fan to ensure the smooth operation of the cooling system.
2. Parameter verification: Regularly verify the parameter settings of the smc cylinders to ensure they remain consistent with actual application requirements.
3. Fault diagnosis: When the equipment fails, promptly check the fault code and troubleshoot according to the fault diagnosis guide in the manual.
Precautions
1. Environmental conditions: Avoid using the product in high-temperature, high-humidity, or strong electromagnetic interference environments to prevent affecting its performance and lifespan.
2. Power requirements: Ensure the power voltage is stable to avoid damage to the smc cylinders from voltage fluctuations. After the equipment is powered off, wait for a certain period before powering it back on to prevent damage to the equipment.
3. Safe operation: Avoid contact with live parts during equipment operation to ensure the safety of operators. When performing maintenance and inspection, the power must be cut off, and the capacitor must be fully discharged.
Frequently Asked Questions (FAQ)
How to perform motor self-tuning?
The importance of motor self-tuning: Motor self-tuning is an essential step to ensure the matching of the inverter with smc regulator valve and the motor, which can improve control accuracy and system stability. When performing self-tuning, you first need to set the motor's nameplate parameters, including motor power, rated voltage, rated current, etc.
Precautions during the self-tuning process: During self-tuning, the inverter with smc regulator valve will inject current into the motor, so it is necessary to ensure that the motor and inverter with smc regulator valve are correctly connected and that the inverter with smc regulator valve is in a ready state. At the same time, ensure that the motor is in a stationary state to avoid damage to the motor during the self-tuning process.
The effect after self-tuning: After completing the self-tuning, the inverter with smc regulator valve will automatically adjust the control parameters according to the actual parameters of the motor to achieve the best operating effect. This helps to improve the system's response speed and control accuracy, meeting the application requirements for high-precision control.
How to configure the communication interface of the inverter with smc regulator valve?
Communication interface type: The FR-D740-022SC-EC inverter with smc regulator valve is equipped with the Modbus-RTU protocol and supports the RS485 communication interface. Users can choose the appropriate communication interface for configuration according to actual needs.
Communication line connection: When configuring the communication interface, it is necessary to ensure the correct connection of the communication line. Use shielded cables for connection and ensure that the shielding layer of the cable is properly grounded to reduce electromagnetic interference.
Communication parameter settings: According to the requirements of the communication protocol, set the communication address, baud rate, data bits, stop bits, etc., of the inverter with smc regulator valve. At the same time, ensure that the communication parameters are consistent with the upper computer to achieve a reliable communication connection.
How to choose the power range of the inverter with smc regulator valve?
Choose according to load requirements: When selecting the power range of the inverter with smc regulator valve, it is necessary to determine it according to the actual load condition of the motor. If the load is light, you can choose an inverter with smc regulator valve that matches the rated power of the motor; if the load is heavy or there is a large starting torque requirement, you need to choose an inverter with smc regulator valve with a slightly higher power.
Consider safety factor: When selecting the power range, the safety factor of the system should also be considered. It is usually recommended to choose an inverter with smc regulator valve with a power slightly higher than the rated power of the motor to cope with load fluctuations and emergencies.
Overload capacity: The FR-D740-022SC-EC inverter with smc regulator valve has a certain overload capacity and can withstand a load exceeding the rated power in a short time. However, long-term overload will affect the lifespan and performance of the inverter with smc regulator valve, so it is best to avoid long-term overload operation when selecting the power range.
What is the cooling method of the inverter with smc regulator valve?
Cooling method: The FR-D740-022SC-EC inverter with smc regulator valve uses forced air cooling, Installation requirements: When installing the inverter with smc regulator valve, ensure there is enough space around it for air circulation. Avoid installing the inverter with smc regulator valve in a closed or poorly ventilated environment, which may affect the cooling effect.
Maintenance and care: Regularly clean the dust on the fan and heat sink to effectively prevent equipment overheating due to poor cooling. At the same time, check the operation of the fan to ensure it is working properly.
How to avoid electromagnetic interference of the inverter with smc regulator valve?
Built-in filter: the inverter with smc regulator valve is equipped with an EMC filter, which complies with relevant electromagnetic compatibility standards and can effectively suppress electromagnetic interference with magnetic valves.
Wiring precautions: When wiring, try to avoid placing signal lines close to power lines to reduce electromagnetic interference with magnetic valves. At the same time, use shielded cables for signal line connections and ensure the shielding layer is properly grounded.
Grounding measures: Good grounding is an important means to reduce electromagnetic interference. Ensure the equipment is properly grounded and complies with national and local electrical safety regulations.
What are the protection functions of the inverter with smc regulator valve?
Overload protection: When the motor load exceeds the rated value, the inverter with smc regulator valve will automatically reduce the frequency or stop running to protect the motor andinverter with smc regulator valve.
Overheat protection: the inverter with smc regulator valve is equipped with a temperature sensor inside. When the temperature exceeds the set value, it will automatically shut down to prevent damage caused by overheating.
Overvoltage and undervoltage protection: When the power voltage is too high or too low, the inverter with smc regulator valve will automatically shut down to protect the equipment. In addition, it also has short-circuit protection and phase loss protection functions to ensure the safe operation of the system.
How to perform regular maintenance on the inverter with smc regulator valve?
Appearance inspection: Regularly check the appearance of the inverter with smc regulator valve for damage or abnormalities, such as cracks in the casing or loose screws.
Cooling system maintenance: Clean the dust on the fan and heat sink to ensure the normal operation of the cooling system. Check the operation of the fan and replace it in time if there are any abnormalities.
Electrical connection check: Check whether the connections of the power and signal lines are firm to ensure good contact. At the same time, check the operating state of the motor and deal with any abnormalities in time.
What should be noted when installing the inverter with smc regulator valve?
Installation location: Choose an environment with good ventilation, free of dust, and non-corrosive gases for installation. Avoid installing the inverter with smc regulator valve in high-temperature, high-humidity, or strong electromagnetic interference environments.
Installation method: Ensure the inverter with smc regulator valve is installed vertically for proper heat dissipation. Use appropriate fixing methods during installation to prevent equipment damage from vibrations.
Power connection: When connecting the power supply, ensure the power cable specifications meet the requirements and pay attention to the correct phase sequence. At the same time, ensure the equipment is properly grounded.
How to choose the control mode of the inverter with smc regulator valve?
Choose according to application requirements: For applications requiring high-precision speed control, you can choose the sensorless vector control mode; for general constant-speed control applications, you can choose the V/F control mode.
Control mode characteristics: The sensorless vector control mode can achieve high-precision speed and torque control and is suitable for applications with high control accuracy requirements. The V/F control mode is simple and easy to use and is suitable for general constant-speed control.
Parameter settings: After selecting the control mode, set the parameters according to specific application requirements to achieve the best control effect.
How to set the frequency setting channel of the inverter with smc regulator valve?
Frequency setting method: The frequency can be set through the inverter with smc regulator valve panel, external analog signals, or digital signals. Users can choose the appropriate frequency setting method according to actual application requirements.
Signal source requirements: When setting the frequency setting channel, ensure the stability and accuracy of the signal source. For example, when using external analog signals for frequency setting, ensure the stability and anti-interference ability of the signal.
Parameter configuration: According to the selected frequency setting method, perform the corresponding parameter configuration. For example, for external analog signal setting, set the input range of the signal and the corresponding frequency range.
