Description: Open-shelf power supplies are available in a variety of rated output voltages and are available in a variety of configuration options. Products and IEC60950-1/62368-1 of the main safety standards. ** The new PJB series has built in high power boost performance, which can maintain a 200% power boost for up to 10 seconds. Product design is under the best industrial footprint standards.
Product characteristics
Major safety certifications, including IEC/EN/UL 60950-1, IEC/EN/UL 62368-1, IEC/EN 60335-1, IEC/EN 61558-1 and IEC/EN 61558-2-16
AC Input Voltage Range Soon Available Class I Ring Class II (Dual insulation
300W fan cooling, natural convection cooling power up to 240W
The efficiency can be as high as 94.0%
Built-in main PFC, remote control On/Off, remote sensing signal, Power Good signal and SB (6W) ring Optional 5VSB (6W)
No-load input power consumption < 0.5W, < 0.75mA low leakage current
-40°C extremely low temperature stimulating
Product parameter
Output current: 12.5A
Output voltage: 24V
Output voltage adjustment range: 22.8-25.2Vdc
Output power: 300W
Line voltage adjustment rate: V1 and VSB: < 0.5% (@90-264Vac input, 0-100% load)
load adjustment rate: V1 and VSB: < 1.0% (@90-264Vac input, 0-100% load)
Input voltage: 100-240Vac
Input voltage range: 90-264Vac
Rated input frequency: 50-60Hz
Input frequency range: 47-63Hz
Input current: < 4.0A@115Vac, < 2.0A@230Vac
100% load efficiency:
> 93% @ 115Vac
> 94% @ 230Vac
** Large influx current: < 20A @ 115Vac, < 40A @ 230Vac
Power factor: > 0.95@115Vac & 230Vac
Leakage current: < 0.75mA @ 240Vac
** High power loss: 100% Load: < 23W @ 115Vac & 230Vac
Indicator light: Green LED (DC OK)
Cooling mode: Convection, Fan Cool
Weight: 0.45 kg (0.99 lb)
Size:
127 x 76.2 x 35.8mm
5.00 "x 3.00" x 1.41"
Operating temperature: -25°C to +70°C (Cold Start -40°C)
Storage temperature: -40°C to +85°C
Condensing Humidity: 5 to 95% RH (Non-Condensing)
