The SMC solenoid valve SY7000-27-1F-Q is a high-performance industrial automation control component from the SY7000 series. This product is characterized by its compact design, high flow rate, and low power consumption. It is widely used in applications that require precise control of fluid direction and pressure. The SY7000 series is suitable for various industrial automation scenarios, including automated machinery, SMC pneumatics automation components, and direction control valve in solenoid valve base systems.
Product Parameters
Series: SY7000
Connection port thread: G 1/4
Thread standard: G
Thread size: 1/4 inch
Voltage: 24V DC (standard voltage)
Power consumption: Low power design, suitable for continuous long-term operation
Operating temperature range: -10°C to +50°C
Sealing method: Rubber sealing
Installation method: Can be used individually or in combination with a manifold system
Product Features
High flow rate and low power consumption: The SY7000 series solenoid valve achieves high flow rates within a compact design while maintaining low power consumption, making it ideal for energy-saving applications.
Multiple installation options: Supports unit assembly, installation on a connecting rod, or integration with a manifold system.
LED display: Equipped with an LED indicator light for easy monitoring of device status.
Manual override function: Features a non-locking manual override function, allowing manual control in emergency situations.
Application Scenarios
Automated machinery: Controls the direction and speed of SMC pneumatics automation components and tools.
Direction control valve in solenoid valve base system: Used in applications requiring precise control of airflow direction and pressure, such as food processing, chemical, and medical equipment.
Usage Instructions
Installation and Wiring
Installation environment: Choose a dust-free, non-corrosive gas, and low electromagnetic interference environment, ensuring good heat dissipation for the device.
Wiring requirements: Follow the wiring diagram in the product manual strictly to ensure correct connections for power and signal lines.
Grounding protection: Ensure proper grounding of the device in accordance with national and local electrical safety standards.
Parameter Settings
Basic parameters: Set voltage, power consumption, and operating temperature range according to application requirements.
Advanced functions: Configure manual override and LED indicator functions as needed.
Maintenance and Inspection
Regular inspection: Check for external damage, dust accumulation on heat sinks, and proper operation of fans.
Parameter verification: Regularly verify device settings to ensure they match application requirements.
Fault diagnosis: When a fault occurs, check the fault code and troubleshoot according to the manual.
Precautions
Environmental conditions: Avoid using in high-temperature, high-humidity, or strong electromagnetic interference environments.
Power requirements: Ensure stable power supply voltage to prevent damage from voltage fluctuations.
Safety operation: Avoid contact with live parts during operation to ensure operator safety.
Frequently Asked Questions (FAQ)
What is the power consumption?
Power consumption feature: The solenoid valve features a low power design with a standard power consumption of only 0.35W, suitable for continuous long-term operation.
Energy-saving advantage: Low power consumption not only reduces energy use but also minimizes device heat generation, extending its lifespan.
Application scenario: This low-power feature makes it particularly suitable for battery-powered or energy-saving automation systems.
What is the operating temperature range?
Temperature range: The operating temperature range of the solenoid valve is -10°C to +50°C.
Environmental adaptability: This wide temperature range design allows it to adapt to various harsh industrial environments.
Precautions: When using in extreme temperatures, additional protective measures such as insulation or heating are recommended.
What installation options are available for the SY7000-27-1F-Q solenoid valve?
Installation options: The solenoid valve supports multiple installation methods, including unit assembly, connecting rod installation, or integration with a manifold system.
Flexibility: This diverse installation flexibility allows it to meet different system design requirements.
Installation suggestions: Ensure secure connections and minimize vibration impact during installation.
How to choose the voltage?
Standard voltage: The standard voltage for the solenoid valve is 24V DC.
Voltage selection: Choose the voltage based on the solenoid valve base system's power supply conditions and device requirements.
Precautions: Ensure stable power supply voltage to prevent damage from voltage fluctuations.
What is the maintenance cycle?
Regular maintenance: It is recommended to perform a visual inspection and cleaning every three months.
Maintenance content: Includes cleaning dust from heat sinks and fans, and checking the electrical connections.
Importance: Regular maintenance extends device lifespan and ensures long-term stability and reliability.
What is the sealing method?
Sealing type: The solenoid valve uses rubber sealing.
Sealing advantage: Rubber sealing provides excellent sealing performance, effectively preventing leaks.
Precautions: Regularly inspect the wear of the sealing components and replace them as needed.
What is the response time?
Response speed: The response time of the solenoid valve is typically within 10ms.
Fast response: This capability meets the needs of high-precision control.
Application scenario: Suitable for automation systems requiring rapid switching and high-frequency operations.
Does it support manual operation?
Manual override function: The solenoid valve features a non-locking manual override function.
Operation method: In emergency situations, temporary operation can be performed using a manual button.
Precautions: Manual operation is for emergencies only; long-term reliance may affect device performance.
Does it support LED indication?
LED display: The solenoid valve is equipped with an LED indicator light.
Indication function: The LED light provides real-time status monitoring of the device.
Application scenario: The LED indicator is very practical for remote monitoring or quick device status diagnosis.
How is the compatibility?
Compatibility:The solenoid valve is compatible with various SMC pneumatics automation components and PLC control systems.
Connection method: Supports multiple connection methods, including G 1/4 thread connections.
Precautions: Ensure the system's voltage and interfaces match the solenoid valve during connection.
