Introduction: ATV310 is a mature and reliable, simple to use, cost-effective vector inverter. Power range 0.37 -- 30kW, constant load/heavy load compatible, heavy load applications can achieve 55℃ no capacity reduction.
Product parameter
Product Line: Easy Altivar 310
Product type: Inverter
Application: simple machinery
Assembly method: with heat sink
Product name: ATV310
Number of grid phases: three phases
Rated supply voltage [Us] : 380... 460 V - 15… 10%
Motor power (kW) : 18.5kW
Motor power: 25 hp
Noise level: 50 dB
Product function: asynchronous motor
EMC filter: No EMC filter
Cooling mode: Integrated fan
Power supply frequency: 50/60 Hz +/- 5%
Communication port: Protocol serial port Modbus
Port type: RJ45 (Front panel) Serial port Modbus is available
Physical port: RS485-2 cable is suitable for serial Modbus
Transmission frame: RTU applies to serial Modbus
Number of addresses: 1... 247 Serial port Modbus is applicable
Line current:
55.3A
54.1A
Apparent power:
36.5 kVA
35.7 kVA
Expected route Isc:
22 kA
5 kA
Continuous output current:
39 A in... Up 4 kHz
43 A in... Up 4 kHz
** Large transient current:
58.5A for 60 s
47.3A Applies to 60 s
Power consumption W:
499.6W In
588 W is In
Inverter output frequency: 0.5... 400 Hz
Rated switching frequency: 4 kHz
Switching frequency: 2... 12 kHz adjustable
Speed range: 1... 20
Instantaneous over-torque: 170... The 200% rated motor torque depends on the rating of the drive and the type of motor
Braking torque:
Up to 150% of rated motor torque with high inertia brake resistors
Up to 70% motor torque without brake resistor
Output voltage: 380... 460 V three-phase
Electrical connection: terminal, clamping force: 10 mm² (L1, L2, L3, PA/+, PB, U, V, W)
Tightening torque: 2.2... 2.4N.m
Isolation: The circuit between power and control
Analog input quantity: 1
Discrete input number: 4
Linearity error: '+/ -0.3% ** Maximum value suitable for analog input
Analog output quantity: 1
Brake to stop: DC injection, <30 s
Time constant: 20 ms +/ -1 ms for model changes
Operating position: Vertical +/ -10 °
Height: 330 mm
Width: 180 mm
Depth: 191 mm
Net weight: 6.3kg
IP protection level:
IP20 has no blind plate in the upper part
IP41 top margin
Pollution level: 2 according to EN/IEC 61800-5-1
Shock resistance: 15 gn for 11 ms in accordance with EN/IEC 60068-2-27
Relative humidity:
5... 95% condensation free according to IEC 60068-2-3
5... 95% dripping free in accordance with IEC 60068-2-3
Storage ambient temperature: -25... 70 °C
Ambient temperature:
- 10... 55 °C without capacity reduction
55... 60 °C Remove the protective cover at the top of the inverter. Current derating is 2.2% / °C
Working altitude: <= 1000 m None
