Technical data
SIMATIC S7-200 SMART, Analog input SM AI08, 8 Analog input, 0... 10V, 0... 5V, +/-5V, +/-2.5V or 0/4-20mA; 11 Bit+ sign Bit (12 Bit ADC)
General information
Product type logo SM AI08, AI 8x12 bit
CiR configuration in action
Parameter assignment can be changed in RUN mode. No
Supply voltage
Voltage type of the power supply DC
Rating (DC) 24 V; -15 / +20 %
Allowable range, lower limit (DC) 20.4V
The upper limit (DC) is 28.8V
Input current
Consumption current, typical value 60 mA
Consumption current, maximum 80 mA
From the backplane bus DC 5 V, typical value 61 mA
From the backplane bus DC 5 V, Max 80 mA
Power loss
Power loss, typical value 2 W
Analog input
The number of analog inputs is 8
Input range
● Voltage is
● Current is
● Thermocouple No
● Resistance thermometer No
● Resistance No
Input analog value composition
Integration and conversion time/resolution per channel
● Resolution (bits including symbols) with overmodulation, up to 12 bits
dimension
Width 45 mm
Height 100 mm
Depth 81 mm
weight
Weight, about 186 g
