Technical data
SIMATIC S7-200 SMART, Analog I/O SM AM06, 4 Analog inputs /2 Analog Outputs, 0.. 10V, 0.. 5V, 0/4.. 20mA, +/-5V, +/-2.5V, 12 Bit resolution or 4... 20mA, +/-10V 11 Bit resolution
General information
Product Type Logo SM AM06, AI 4x12 bit, AQ 2x11 bit
CiR configuration in action
Parameter assignment can be changed in RUN mode. No
Supply voltage
Voltage type of the power supply DC
Rating (DC) 24 V; -15 / +20 %
Allowable range, lower limit (DC) 20.4V
The upper limit (DC) is 28.8V
Input current
Consumption current, typical value 60 mA
From the backplane bus DC 5 V, typical value 80 mA
Power loss
Power loss, typical value 2 W
Analog input
The number of analog inputs is 4
Input range
● Voltage is; ±10V, ±5V, ±2.5V
● Current is; 0 to 20 mA
● Thermocouple No
● Resistance thermometer No
● Resistance No
Input range (rating), voltage
● -10 V to +10 V Yes
- Input resistance (-10 V to +10 V) 9 MΩ
● -2.5V to + 2.5V Yes
- Input resistance (-2.5V to + 2.5V) 9 MΩ
● -5 V to +5 V Yes
- Input resistance (-5 V to +5 V) 9 MΩ
Input range (rating), current
● 0 to 20 mA Yes
- Input resistance (0 to 20 mA) 250 Ω
Analog output
The number of analog output terminals is 2; Current or voltage
Output range, voltage
● -10 V to +10 V Yes
Output range, current
● 0 to 20 mA Yes
Load resistance (in rated output range)
● Minimum voltage output 1 kΩ
● The maximum value of current output is 500 Ω
Input analog value composition
Integration and conversion time/resolution per channel
● Resolution (bits including symbols) with overmodulation, up to 12 bits; Voltage mode: 11 bit + symbol bit, current mode: 11 bit
● For interference frequency f1 (unit Hz), interference voltage suppression 10/50/60/400 Hz
Measurement filtering
● Parameterizable is; There are 4 levels: 1x, 4x, 16x, 32x cycle time
● Grade: None; 1x
● Level: weak Yes; 4x
● Grade: medium is; 16x
● Level: strong is; 32x
Composition of analog values at the output end
Integration and conversion time/resolution per channel
● Resolution (bits including symbols) with overmodulation, up to 11 bits; Voltage mode: 11 bit + symbol bit, current mode: 11 bit
● Synchronous operation mode resolution (including overrange) Voltage mode: 10 bit + symbol bit, current mode: 10 bit
Alarm/diagnosis/status information
The diagnostic function is
diagnosis
● Power supply voltage monitoring is
● The broken line is
● Short circuit is
Diagnostic display LED
● For input side status is
● For output end status is
Protection level and protection category
Protection level IP Address IP20
Standards, licenses, certificates
CE mark is
dimension
Width 45 mm
Height 100 mm
Depth 81 mm
weight
Weight, about 173.4g
