Technical data
SIMATIC S7-200 SMART, SM AI04 analog input, 4 analog input, 4xAI thermocouple
General information
Product type logo SM AT04, AI TC 4x16 bit
Supply voltage
Voltage type of the power supply DC
Rating (DC) 24 V
Allowable range, lower limit (DC) 20.4V
The upper limit (DC) is 28.8V
Reverse polarity protection is
Input current
Consumption current, typical value 30 mA; Current consumption of 24 V DC user power supply
Consumption current, maximum 40 mA; 20.4V DC and maximum load
From the backplane bus DC 5 V, typical value 70 mA; 5 V DC from the CPU module
From the backplane bus DC 5 V, Max 80 mA
Power loss
Power loss, typical value 1.5 W
Analog input
The number of analog inputs is 4
Input range
● Voltage no
● Current No
● Thermocouple is
● Resistance thermometer No
● Resistance No
Analog output
The number of analog outputs is 0
Input analog value composition
Integration and conversion time/resolution per channel
● Resolution (bits including symbols) with overmodulation, up to 16 bits
dimension
Width 45 mm
Height 100 mm
Depth 81 mm
weight
Weight, about 125 g
