Technical data
SIMATIC S7-200 SMART, digital input SM DI08, 8 DI, 24V DC, perfusion current/pull current
General information
Product Type Label SM DI08, DI 8x24 VDC
Supply voltage
Rating (DC) 24 V
Allowable range, lower limit (DC) 20.4V
The upper limit (DC) is 28.8V
Power loss
Power loss, typical value 1.5 W
Digital input
Number of input terminals 8
● In the component 2
The parallel switch at the input is
Input characteristics comply with IEC 61131, type 1 is
The number of inputs that can be controlled simultaneously
All mounting positions
- The maximum value is 40 ℃ and the maximum value is 8 ℃
Horizontal mounting position
- The maximum value is 50 ℃ and the maximum value is 8 ℃
Vertical mounting position
- The maximum value is 40 ℃ and the maximum value is 8 ℃
Input voltage
● Input voltage type DC
● Rating (DC) 24 V
● For signal "0" < 5 V DC
● For signal "1" +15 to +30 V
Input current
● For signal "0", maximum (allowed closed circuit current) 1 mA
● For signal "1", minimum value 2.5mA
● For signal "1", the maximum is 5 mA
● For signal "1", the typical value is 4 mA
Input delay (when input voltage is rated)
For standard input
- When the value ranges from 0 to 1, the maximum value is 200 µs
- When the value ranges from 1 to 0, the maximum value is 200 µs
Conductor length
● Shielding, maximum 500 m
● Unshielded, maximum 300 m
Digital output
Number Number of output terminals 0
Alarm/diagnosis/status information
Diagnostic display LED
● For input side status is
Potential isolation
Digital input potential isolation
● Between the channels is; Photoelectric coupler
insulation
Insulation test, using 500V AC for 1 minute
Protection level and protection category
Protection level IP Address IP20
Standards, licenses, certificates
CE mark is
dimension
Width 45 mm
Height 100 mm
Depth 81 mm
weight
Weight, about 141.4g
