The main function and composition of the configuration software of MCGS Tong - state embedded edition are introduced
Published:2023-06-01 11:02:37
The main function of MCGS embedded configuration software
1. Simple and flexible visual operation interface: all Chinese and visual development interface is adopted, which meets the usage habits and requirements of Chinese people.
2. Strong real-time performance and good parallel processing performance: it is a real 32-bit system, which carries out time-sharing parallel processing of tasks by thread.
3, rich and vivid multimedia picture: in the form of images, symbols, reports, curves and other forms, to provide operators with relevant information in time.
4. Perfect security mechanism: provides a good security mechanism, which can set different operation rights for multiple users at different levels.
5. Powerful network function: It has powerful network communication function.
6, diversified alarm function: provide a variety of different alarm methods, with rich alarm types, convenient for users to carry out
The composition of MCGS embedded configuration software
The user application system generated by MCGS embedded edition consists of five parts: main control window, device window, user window, real-time database and operation strategy.
1. Main control window: The main framework of the application system is constructed. It is used to configure parameters related to the whole project. You can set the cover window, permissions for running the project, startup screen, memory screen, reserved disk space, etc.
2. Device window: It is the medium through which the application system communicates with external devices. Specially used to place different types and functions of equipment components, to achieve the operation and control of external equipment. The device window collects the data of the external device through the device component, sends it to the real-time database, or outputs the data in the real-time database to the external device.
3. User window: realized the "visualization" of the data and process of the application system. All visual interfaces in the project are built in the user window. Three different types of graphic objects can be placed in the user window: primitives, symbols, and animators. By placing different graphical objects in the user window, users can construct a variety of complex graphical interfaces to "visualize" data and processes in different ways.
4, real-time database: is the core of the application system. The real-time database acts as a data processing center as well as a common data exchange area. The real-time data collected from the external equipment is fed into the real-time database, and the data of other parts of the system operation also comes from the real-time database.
5. Operation strategy: It is the means to achieve perfect control over the operation process of the application system. The operation policy itself is a framework provided by the system, in which a "policy row" composed of policy condition components and policy components is placed. Through the definition of the operation policy, the system can operate tasks in accordance with the set sequence and conditions, and realize the perfect control of the working process of external equipment.
-
