Fuji FRN160G1S-4C Inverter: Precision VFD Frequency Seamless Connection

The Fuji FRN160G1S 4C is a high performance vfd inverter designed for industrial applications, offering precise vfd frequency control and seamless vfd connection for motor integration. With a rated power of 160kW, it supports three phase 380 480V power input and deliver···

  • Contact Us Contact On WhatsApp
  • 010-64225983

    +8613811814778

    info@zhongpingtech.com

    Building 26, Liyuan Community, Chaoyang District, Beijing, China

The Fuji FRN160G1S 4C is a high performance   vfd inverter   designed for industrial applications, offering precise   vfd frequency   control and seamless   vfd connection   for motor integration. With a rated power of 160kW, it supports three phase 380 480V power input and delivers a wide output frequency range (0.2 400Hz), ensuring exceptional speed and torque control. Built with advanced   vfd inverter   technology, it features multiple control modes, including V/F control, vector control, and PID control, making it ideal for complex automation tasks. Known for its efficiency, stability,

and reliability, the FRN160G1S 4C is widely used in fans, pumps, conveyors, and compressors, helping users achieve energy savings and precise   vfd frequency   management. Its robust design ensures seamless   vfd connection   with various motor types, enhancing operational flexibility.

Fuji FRN160G1S-4C Inverter: Precision VFD Frequency   Seamless Connection

    Product Specifications



    Rated Power  : 160kW, suitable for high power motor drive requirements.

    Input Voltage  : Three phase 380 480V, compatible with global power grid standards.

    Rated Current  : 320A@50°C, ensuring stable operation in high temperature environments.

    Output Frequency Range  : 0.2 400Hz, providing a broad speed adjustment range for   vfd frequency   control.

    Control Methods  : V/F control, vector control, and PID control, supporting diverse application scenarios.

    Communication Interface  : RS485 communication, compatible with Modbus RTU protocol, facilitating seamless   vfd connection   with PLCs, HMIs, and other devices.

    Protection Features  : Overload, overheating, overvoltage, undervoltage, and short circuit protection, ensuring safe operation.

    Environmental Adaptability  : Operating temperature range of  10°C to +50°C, suitable for harsh industrial environments.







    Product Features



1.   High Precision Control  : Supports sensorless vector control, enabling high precision speed and torque control, especially for applications requiring dynamic responsiveness.

2.   Versatility  : Built in PID control, multi speed control, and timer control functions to meet complex control needs.

3.   Energy Efficiency  : Optimizes motor operating parameters to significantly reduce energy consumption, ideal for energy saving applications like fans and pumps.

4.   User Friendly Design  : Equipped with an LCD display and an intuitive operation panel for easy parameter setting and status monitoring.

5.   Durability and Reliability  : Utilizes high quality components and forced air cooling to ensure long term stable operation.







    Application Scenarios



1.   Fan and Pump Control  : Adjusts motor speed to achieve energy savings, suitable for HVAC and water treatment industries.

2.   Conveyor Drive  : Precisely controls conveyor speed and start/stop operations, improving logistics and production line efficiency.

3.   Compressor Control  : Optimizes compressor operating parameters to reduce energy consumption and extend equipment lifespan.

4.   Industrial Machinery  : Enhances machining accuracy and product quality by precisely controlling motor speed in equipment like machine tools and mixers.







    User Manual



     Installation and Wiring

    Installation Environment  : Choose a well ventilated, dust free, and non corrosive environment to ensure proper heat dissipation.

    Wiring Requirements  : Strictly follow the wiring diagram in the manual for power, signal, and motor connections, ensuring correct phase sequence.

    Grounding Protection  : Ensure proper grounding of the device in compliance with electrical safety standards.



     Parameter Settings

    Basic Parameters  : Set motor rated power, voltage, and current to ensure compatibility between the inverter and the motor.

    Control Mode  : Select V/F control, vector control, or PID control based on application requirements.

    Advanced Functions  : Configure multi speed and timer control functions to meet complex application needs.



     Maintenance and Inspection

    Regular Checks  : Clean dust from the heat sink and fan, and inspect electrical connections for tightness.

    Parameter Verification  : Periodically verify parameter settings to ensure they align with actual requirements.

    Fault Diagnosis  : Use fault codes and the manual to troubleshoot and resolve issues.







    Precautions

1.   Environmental Conditions  : Avoid using the inverter in high temperature, high humidity, or strong electromagnetic interference environments.

2.   Power Requirements  : Ensure stable power supply voltage to prevent damage from voltage fluctuations.

3.   Safe Operation  : Ensure power is disconnected and capacitors are discharged before operating or maintaining the device.



    Frequently Asked Questions (FAQ)



1.   How to Perform Motor Auto Tuning on the FRN160G1S 4C Inverter?

   Motor auto tuning is a critical step to ensure compatibility between the device and the motor. First, input the motor’s nameplate parameters (e.g., power, voltage, current), then initiate the auto tuning process. During auto tuning, the device injects current into the motor to measure its characteristics, so ensure the motor is stationary. Once completed, the device automatically adjusts control parameters for optimal performance.



2.   How to Configure the Communication Interface of the FRN160G1S 4C Inverter?

   The device supports RS485 communication and is compatible with the Modbus RTU protocol. First, connect the communication cable, ensuring the shield is properly grounded. Then, set the communication address, baud rate, data bits, and stop bits in the device parameters to match the host device. Once configured, you can monitor and adjust device parameters via the host device.



3.   How to Select the Power Range for the FRN160G1S 4C Inverter?

   Select the device power based on the motor’s rated power and load characteristics. For constant loads, choose a device matching the motor’s power. For variable loads or high starting torque applications, opt for a slightly higher power device. Also, consider the system’s safety factor to avoid prolonged overload operation.



4.   What is the Cooling Method for This Device?

   The device uses forced air cooling with a high performance cooling fan. During installation, ensure sufficient space around the device for airflow and avoid placing it in enclosed or poorly ventilated areas. Regularly clean dust from the fan and heat sink to extend its lifespan.



5.   How to Avoid Electromagnetic Interference with This Device?

   The device has a built in EMC filter to suppress electromagnetic interference. During wiring, separate signal and power cables and use shielded cables for signal connections. Additionally, ensure proper grounding of the device in compliance with electrical safety standards.



6.   What Protection Features Does This Device Offer?

   The device provides overload, overheating, overvoltage, undervoltage, short circuit, and phase loss protection. When an anomaly is detected, the device automatically shuts down to prevent damage. You can also adjust protection trigger conditions through parameter settings to suit different application needs.



7.   How to Perform Regular Maintenance on This Device?

   Regularly inspect the device’s exterior for damage and clean dust from the heat sink and fan. Check electrical connections for tightness and ensure power and signal cables are securely connected. Periodically verify parameter settings to ensure they align with actual requirements. Address any anomalies promptly.



8.   What Should Be Considered During Installation of This Device?

   Install the device in a well ventilated, dust free, and non corrosive environment, avoiding high temperature, humidity, or strong electromagnetic interference. Mount the device vertically to facilitate heat dissipation. Use appropriately sized cables for power connections and ensure correct phase sequence. Additionally, ensure proper grounding of the device.



9.   How to Choose the Control Mode for This Device?

   For applications requiring high precision control, select vector control mode. For general constant speed control, choose V/F control mode. If the application requires closed loop control (e.g., pressure or flow control), enable PID control mode. Configure parameters based on specific needs for optimal control performance.



10.   How to Set the Frequency Reference Channel for This Device?

    The frequency reference can be set via the device panel, external analog signals, or digital signals. First, select the frequency reference method (e.g., panel or external signal), then configure related parameters (e.g., input range and frequency range). Ensure the signal source is stable and accurate for reliable frequency control.
