Technical data
SIMATIC HMI TP1500 Smart, Smart panel, Touch operation, 15 "widescreen TFT display, 16 million colors, PROFINET interface, MPI/PROFIBUS-DP interface, 24MByte Project mode Memory, WEC 2013, The lowest version of project mode WinCC Comfort V14 SP1 with HSP is available
General information
Product type mark TP1500 Comfort
display
The display size is TFT
The screen is 15.4 in diagonal
The screen width is 331.2 mm
The screen height is 207 mm
Number of colors 16 777 216
Resolution (pixel)
● Horizontal image resolution 1 280 pixel
● Vertical image resolution of 800 pixel
backlight
● MTBF background lighting (at 25 °C) 80,000 h
● Adjustable background lighting is; 0-100 %
Operating element
Keyboard font
● Function keys
- The number of function keys is 0
- The number of function keys with LED is 0
● Keys with LED No
● System key No
● Digital keyboard is; On-screen keyboard
● Alphanumeric keyboard is; On-screen keyboard
Touch screen
● Touch screen specifications are; Analog resistance
Procedure operation extension
● Direct key (touch key as S7 input peripheral) 40
Installation mode/Installation
Vertical installation position
Can be installed vertically (portrait format) yes
Can be installed horizontally (landscape format) is
The maximum allowable tilt Angle is 35° without external ventilation
Supply voltage
Voltage type of the power supply DC
Rating (DC) 24 V
Allowable range, lower limit (DC) 19.2 V
The upper limit (DC) is 28.8V
Input current
Consumption current (rated) 1.7A
Turn on the current pulse I²t 0.5A ²·s
power
The typical effective power received is 41 W
processor
Processor type X86
memory
Flash memory is
RAM is
Available memory for user data is 24 Mbyte
Output type
Info LED No
Power LED No
Error LED No
sound
● Buzzer No
● The speaker is
time
clock
● Hardware clock (real-time clock) Yes
● Software clock is
● Cache is; The buffer duration is typically 6 weeks
● Synchronous yes
interface
Number of industrial Ethernet interfaces 2; Two ports (switch) + independent ports
RS 485 Number of ports 1; RS 422/485 interface combination
RS 422 Port number 0; Together with RS 485
RS 232 Number of interfaces 0
Number of USB ports 2; USB 2.0
