The Fuji vfd FRN0022E2S-4C is a high-performance inverter from Fuji’s E2S series, designed to meet the demands of industrial automation and energy efficiency. This vfd drives, with a rated power of 7.5kW, is suitable for a three-phase 380V power supply environment. It provides efficient and stable variable speed drive control for fans, pumps, and other equipment. Thanks to its powerful features and flexible configuration options, the FRN0022E2S-4C has gained widespread application in the industrial sector, helping users achieve energy savings and increased production efficiency.



Fuji Vfd FRN0022E2S-4C: Drives With Variable Speed Function

Product Specifications

Rated Power: 7.5kW

Rated Current: 17.5A

Input Voltage: Three-phase 380V

Frequency Range: 0-400Hz

Control Methods: Supports V/F control and sensorless vector control

Communication Interface: Standard RS485 interface with support for Modbus protocol

Protection Functions: Overload, overheat, overvoltage, undervoltage, short-circuit, and other protection features

Environmental Adaptability: Operates in ambient temperatures ranging from -10°C to +50°C

Product Features

Significant Energy Savings: With optimized control algorithms, the vfd drives automatically adjusts motor speed based on load demand, reducing energy consumption.

High-Precision Control: Sensorless vector control technology enables high-precision speed and torque control.

User-Friendly Panel: Equipped with an easy-to-use control panel that supports multiple parameter settings and real-time monitoring.

Flexible Control Modes: Supports various frequency setting methods, including panel setting, external analog signal setting, and digital signal setting.

Robust Protection: Comprehensive protection mechanisms ensure safe operation of the equipment under various working conditions.

Applications

The FRN0022E2S-4C vfd drivesis widely used in the following areas:

Fan and Pump Control: Used in HVAC, water treatment, and other fields to regulate the speed of fans and pumps, achieving energy savings.

Machine Tool Applications: Such as lathes and drilling machines, where precise motor speed control improves machining accuracy and product quality.

Conveyor Belt Drives: In logistics and packaging industries, controlling the start, stop, and speed adjustment of conveyor belts.

Air Conditioning Equipment Control: Utilizing the built-in “user-defined logic” function to achieve energy-efficient control of air conditioning equipment.

Installation and Wiring

Installation Environment: Choose a well-ventilated, dust-free, and non-corrosive gas environment. Avoid high temperatures, high humidity, and strong electromagnetic interference.

Wiring Requirements: Follow the wiring diagram in the product manual to ensure correct connections of power, signal, and motor cables.

Grounding Protection: Ensure proper grounding of the equipment to comply with electrical safety standards.

Parameter Settings

Basic Parameter Settings: Including motor parameters, control methods, frequency range, etc., set according to the actual application requirements.

Advanced Function Configuration: Such as PID control and multi-speed control, configured based on specific application scenarios.

Maintenance and Inspection

Regular Inspection: Check the vfd drives appearance for damage, dust accumulation on heat sinks, and proper fan operation.

Parameter Verification: Regularly verify the inverter’s parameter settings to ensure they match the application requirements.

Fault Diagnosis: When a fault occurs, promptly check the fault code and follow the troubleshooting guide in the manual to identify and resolve the issue.

Precautions

Environmental Conditions: Avoid using the product in high-temperature, high-humidity, or strong electromagnetic interference environments.

Power Requirements: Ensure stable and uninterruptible power supply voltage to prevent damage to the vfd drives from voltage fluctuations.

Safe Operation: Avoid contact with live parts during operation to ensure operator safety.

Frequently Asked Questions (FAQ)

How to Perform Motor Self-Tuning?

Importance of Motor Self-Tuning: Motor self-tuning is a crucial step to ensure compatibility between the vfd drives and the motor, enhancing control accuracy and system stability. During self-tuning, you need to set the motor’s nameplate parameters, including power, rated voltage, rated current, etc.

Precautions During Self-Tuning: During the self-tuning process, the vfd inverter injects current into the motor. Ensure the motor is correctly connected to the inverter and that the vfd drives is in a ready state. Also, make sure the motor is stationary to avoid damage during self-tuning.

Results of Self-Tuning: After completing self-tuning, the inverter automatically adjusts control parameters based on the actual motor parameters to achieve optimal performance. This improves system response speed and control accuracy, meeting high-precision control requirements.

How to Configure the Communication Interface of the FRN0022E2S-4C Inverter?

Communication Interface Type: The FRN0022E2S-4C inverter supports Modbus-RTU protocol via an RS485 communication interface. Users can configure the interface according to their needs.

Communication Line Connection: Ensure correct connection of the communication lines. Use shielded cables and properly ground the shielding layer to minimize electromagnetic interference.

Communication Parameter Settings: Set the Fuji vfd communication address, baud rate, data bits, stop bits, etc., according to the protocol requirements. Ensure consistency with the upper-level machine’s communication parameters for reliable connection.

How to Choose the Power Range of the Inverter?

Select Based on Load Requirements: When choosing the Fuji vfd power range, consider the actual load of the motor. For light loads, select an inverter matching the motor’s rated power. For heavy loads or applications requiring high starting torque, choose an inverter with slightly higher power.

Consider Safety Margin: It is advisable to select an Fuji vfd with slightly higher power than the motor’s rated power to accommodate load fluctuations and unexpected situations.

Overload Capability: The FRN0022E2S-4C inverter has some overload capacity and can handle loads exceeding rated power for short periods. However, long-term overload can affect the inverter’s lifespan and performance, so avoid continuous overloading when selecting the power range.

What is the Cooling Method of the FRN0022E2S-4C Inverter?

Cooling Method: The FRN0022E2S-4C inverter uses forced air cooling with an internal cooling fan.

Installation Requirements: Ensure sufficient space around the inverter for proper airflow. Avoid installing it in enclosed or poorly ventilated areas to maintain effective cooling.

Maintenance: Regularly clean dust from the fan and heat sink to prevent overheating due to poor cooling. Check the fan’s operation to ensure it is working properly.

How to Avoid Electromagnetic Interference with the FRN0022E2S-4C Inverter?

Built-in Filter: The inverter is equipped with an EMC filter that meets relevant electromagnetic compatibility standards, effectively suppressing electromagnetic interference.

Wiring Precautions: Avoid placing signal cables close to power cables to reduce electromagnetic interference. Use shielded cables for signal connections and ensure proper grounding of the shielding layer.

Grounding: Proper grounding is essential to minimize electromagnetic interference. Ensure the equipment is grounded according to national and local electrical safety regulations.

What Protection Features Does the FRN0022E2S-4C Inverter Offer?

Overload Protection: When the motor load exceeds the rated value, the inverter automatically reduces frequency or stops to protect the motor and inverter.

Overheat Protection: An internal temperature controllers the inverter’s temperature. If it exceeds the set value, the inverter automatically shuts down to prevent damage from overheating.

Overvoltage and Undervoltage Protection: The vfd drives automatically stops when the power supply voltage is too high or too low. It also features short-circuit and phase-loss protection to ensure safe system operation.

How to Perform Regular Maintenance on the Inverter?

Visual Inspection: Regularly check the inverter’s appearance for damage or abnormalities, such as cracks in the casing or loose screws.

Cooling System Maintenance: Clean dust from fans and heat sinks to ensure proper cooling system operation. Inspect fan operation and replace if necessary.

Electrical Connection Check: Verify the secure connection of power and signal cables. Ensure good contact and check the motor’s operating condition to identify and address any issues promptly.

What Precautions Should Be Taken When Installing the FRN0022E2S-4C Inverter?

Installation Location: Choose a well-ventilated, dust-free, and non-corrosive gas environment. Avoid high-temperature, high-humidity, or strong electromagnetic interference areas.

Installation Orientation: Ensure the inverter is installed vertically to facilitate cooling. Use appropriate fixing methods to prevent vibration-related damage.

Power Connection: Ensure the power cable meets the required specifications and check the correct phase sequence. Proper grounding is also essential.

How to Choose the Control Mode of the FRN0022E2S-4C Inverter?

Select Based on Application Needs: For applications requiring high-precision speed control, choose sensorless vector control mode. For general variable speed drive control, V/F control mode is suitable.

Control Mode Features: Sensorless vector control mode offers high-precision speed and torque control for applications with high control accuracy requirements. V/F control mode is simple and easy to use for general variable speed drive control.

Parameter Settings: After selecting the control mode, configure the parameters according to the specific application needs to achieve the best control performance.

How to Set the Frequency Setting Channel of the Inverter?

Frequency Setting Methods: Frequency can be set through the inverter panel, external analog signals, or digital signals. Choose the appropriate method based on your application needs.

Signal Source Requirements: Ensure the stability and accuracy of the signal source. For example, when using external analog signals for frequency setting, ensure signal stability and interference resistance.

Parameter Configuration: Configure the parameters according to the selected frequency setting method. For example, for external analog signal setting, configure the input signal range and corresponding frequency range.
