The Fuji FRN11G1S-4C vfd is a kind of high-performance, multifunctional vfds for three phase motor from the FRENIC-MEGA series by FujiElectric, designed specifically to meet the demands of industrial automation. This kind of vfds has a rated power of 11kW and is suitable for a three-phase 380V power supply. It is equipped with a robust heavy-load capacity and high-precision control performance. It is widely used in applications that require high-precision speed control, fast response, and high starting torque, such as machine tools, conveyors, fans, and pumps.
Product Specifications
Rated Power: 11kW
Rated Voltage: vfd for three phase motor, 380V
Rated Current: 24.5A
Control Modes: Supports PG vector control, sensorless vector control, dynamic torque vector control, and V/F control.
Operation Panel: Equipped with a standard keyboard panel that supports Chinese, English, and Japanese displays, making it convenient for users in different regions.
Energy-Saving Features: Built-in energy-saving operation modes for fans and pumps, using optimized control methods to reduce motor losses.
Product Features
High Starting Torque: Utilizing Fuji Electric's unique dynamic torque vector control method, the vfd can achieve a starting torque of 200% at 0.5Hz, making it suitable for heavy-load starting applications.
Overload Capacity: It has a high overload tolerance, with HD specifications of 200% for 3 seconds/150% for 1 minute, making it ideal for cutting machines and handling equipment.
Multifunctionality: Supports various control functions, such as sway control, speed command function, and anti-slip function, suitable for complex applications like winding and handling.
Easy Maintenance: Designed with a lifespan of up to 10 years, using long-life components. The operation panel is equipped with a USB interface for convenient data backup and parameter rewriting.
Application Scenarios
The Fuji FRN11G1S-4C vfd from the FRENIC-MEGA series by FujiElectric is suitable for a variety of industrial applications, including but not limited to:
Machine Tool Control: Used in lathes, milling machines, and other equipment, providing high-precision speed control and fast response.
Conveyor Belt Drive: In logistics and packaging industries, it controls the start, stop, and speed regulation of conveyor belts.
Fan and Pump Control: In HVAC and water treatment fields, it helps achieve energy savings and reduced consumption.
Winding Equipment: Suitable for winding equipment in industries like cable and textile, through tension control functions.
Instructions for Use
Installation and Wiring
Installation Environment: Choose a well-ventilated, dust-free, and non-corrosive gas environment, avoiding high temperatures, high humidity, and strong electromagnetic interference.
Wiring Requirements: Follow the manual strictly for the connection of the main circuit, control circuit, and grounding terminals, ensuring the correct connection of power, signal, and motor lines.
Grounding Protection: Ensure the equipment is properly grounded, in compliance with electrical safety standards.
Parameter Settings
Basic Parameters: Including motor parameters, control modes, frequency range, etc., set according to the actual application needs.
Advanced Functions: Such as PID control and multi-speed control, can be configured based on specific requirements.
Maintenance and Inspection
Regular Inspection: Check the appearance, heat sink, fan, and other components of the vfd, clean dust, and ensure good heat dissipation.
Parameter Verification: Regularly verify parameter settings to ensure they match the actual needs.
Fault Diagnosis: Troubleshoot and handle issues based on fault codes.
Precautions
Environmental Conditions: Avoid using in extreme temperatures, humidity, and electromagnetic interference.
Power Requirements: Ensure stable power voltage and avoid voltage fluctuations.
Safe Operation: Avoid contact with live parts during operation and disconnect power during maintenance.
FAQs
How to Perform Motor Self-Commissioning?
Importance: Motor self-commissioning is a crucial step to ensure the compatibility between the vfd and the motor, improving control accuracy and system stability.
Precautions: During self-commissioning, ensure the motor is correctly connected to the vfd and is in a stationary state.
Effect: After self-commissioning, the vfd will automatically adjust control parameters based on motor parameters to achieve optimal performance.
How to Configure the Communication Interface?
Interface Type: Supports RS485 communication interface with built-in Modbus-RTU protocol.
Connection Requirements: Use shielded cables for communication lines, ensuring proper grounding of the shielding layer.
Parameter Settings: Set communication address, baud rate, and other parameters according to the communication protocol to match the upper-level machine.
How to Select the Power Range of the Vfd?
Load-Based Selection: Choose the power range based on the actual load of the motor.
Safety Factor: It is recommended to select an vfd with a power rating slightly higher than the motor's rated power.
Avoid Long-Term Overload: Long-term overload can affect the lifespan of the vfd.
What is the Cooling Method?
Cooling Method: Forced air cooling is used.
Installation Requirements: Ensure sufficient space around the installation to avoid poor ventilation.
Maintenance: Regularly clean the fans and heat sinks.
How to Avoid Electromagnetic Interference?
Built-in Filter: The vfd includes an EMC filter, complying with electromagnetic compatibility standards.
Wiring Precautions: Avoid placing signal lines close to power lines and use shielded cables.
Grounding Measures: Ensure proper grounding of the equipment.
What Protection Functions Are Available?
Overload Protection: Automatically reduces frequency or shuts down when the load exceeds the rated value.
Overheat Protection: Automatically shuts down when the temperature exceeds the set value.
Overvoltage and Undervoltage Protection: Automatically shuts down when the power voltage is abnormal.
How to Perform Regular Maintenance?
Appearance Inspection: Check for any damage to the enclosure.
Cooling System Maintenance: Clean the fans and heat sinks to ensure normal operation.
Electrical Connection Check: Ensure power and signal lines are securely connected.
What Should Be Considered During Installation?
Installation Location: Choose a well-ventilated, dust-free environment.
Installation Method: Install vertically to ensure proper heat dissipation.
Power Connection: Ensure the power cable meets the required specifications and is properly grounded.
How to Select the Control Mode?
Based on Application Needs: Choose between sensorless vector control and V/F control.
Control Mode Features: Sensorless vector control is suitable for high-precision applications, while V/F control is suitable for constant speed control.
Parameter Settings: Configure parameters according to the needs.
How to Set the Frequency Setting Channel?
Setting Methods: Frequency can be set through the panel, external analog signals, or digital signals.
Signal Source Requirements: Ensure the signal source is stable.
Parameter Configuration: Set the signal input range and corresponding frequency according to the setting method.
