Technical data
SIMATIC S7-300, positioning component FM 351, for fast/slow drive includes project group status package on CD
Supply voltage
Rating (DC) 24 V
Allowable range, lower limit (DC) 20.4V
The upper limit (DC) is 28.8V
Load voltage L+
● Rating (DC) 24 V
● Allowable range, lower limit (DC) 20.4V
● Allowable range, upper limit (DC) 28.8V
Input current
Consumption current, maximum 350 mA
From the backplane bus DC 5 V, Max 150 mA
Sensor power supply
5 V sensor power supply
● 5V is
● Output current, maximum 350 mA
● Wire length, maximum 32 m
24 V sensor power supply
● 24 V is
● Output current, maximum 400 mA; Each channel
● Wire length, maximum 100 m
Power loss
Power loss, typical value 7.9 W
Digital input
Number of input terminals 8
Features reference CAM, flip CAM, float actual value record, start/stop positioning run
Input voltage
● Rating (DC) 24 V
● For signal "0" -3 to +5V
● For signal "1" +11 to +30V
Input current
● For signal "0", maximum (allowed closed circuit current) 2 mA
● For signal "1", the typical value is 6 mA
Digital output
Number of output terminals 8
Function Fast motion, slow motion, run right, run left
Short circuit protection is
Output voltage
● Rating (DC) 24 V
● For signal "1", minimum value UP-0.8V
Output current
● For signal "1" allowable range of 0 to 60 ℃, minimum value 5 mA; Up maximum time
● For the signal "1" allowable range of 0 to 60 ℃, the maximum 600 mA; Up maximum time
● For the residual current of signal "0", the maximum is 0.5mA
sensor
Connectable sensor
● Incremental encoder (symmetric) Yes
● Incremental encoder (asymmetric) Yes
● Absolute encoder (SSI) Yes
● Double wire sensor is
-- The maximum allowable closed-circuit current (two-wire sensor) is 2 mA; When the signal is "0", the maximum is 2 mA; When the signal is "1", the maximum is 6 mA
Sensor signal, incremental encoder (symmetric)
● Track marking signal A, not A, B, not B
● Zero mark signal N, not N
● Input voltage 5 V differential signal (physical RS 422)
● Input frequency, maximum 0.5MHz
Sensor signal, incremental encoder (asymmetric)
● Track marking signal A, B
● Zero mark signal N
● Input voltage 24 V
● Input frequency, maximum 50 kHz; When the wire length is 25 m, it is 50 kHz. When the wire length is 100 m, it is 25 kHz
Sensor signal, absolute encoder (SSI)
● Input signal 5 V differential signal (physical RS 422)
● DATA signal DATA, not data
● Clock signal CL, notCL
● The packet length can be 13 or 25 characters
● Pulse repetition frequency, maximum 1.5MHz
● Gray code Yes
● Shielding wire length, maximum 200 m; The maximum is 188 kHz
Potential isolation
Digital input potential isolation
● Digital input potential isolation Yes
Digital output potential isolation
● Digital output potential isolation is
Environmental requirements
Operating ambient temperature
● Minimum value 0 °C
● Maximum 60 °C
Ambient temperature during transportation/storage
● Minimum value -40 °C
● Maximum 70 °C
Connect technology/title
The required front plug 1x 20 pins
dimension
Width 80 mm
Height 125 mm
Depth 120 mm
weight
Weight, about 550 g
