6ES72411AA220XA0 Description: Siemens Siemens PLC modem module 6ES72411AA220XA0
Model feature introduction
EM241 Modem module
The EM241 modem module extends the functionality of the S7-200 micro PLC to remote communication. It connects directly to the S7-200's extended input/output bus without using a CPU communication interface. The baud rate is self-negotiable, depending on line quality, and can be adjusted between 300 baud and 33.6K baud (V.34bis). The hardware rotary switch supports many ** * standards. All other Settings are stored in the PLC's variable memory. Support pulse or tone dialing, as well as callback and password protection.
This module supports four modes: Mode 1: Micro/WIN Programming Micro/WIN connects to the EM241 modem module to allow access to PLC programs. Modem passwords and callbacks are supported. Mode 2: Modbus Master Configuration/Slave Configuration In Modbus slave configuration mode, the module accepts Modbus instructions. In Modbus master configuration mode, PLC can initiate Modbus instruction. Mode 3: SMS messaging and paging EM241 calls the messaging service center and transmits the message. Depending on the service option, the message may be sent to a cell phone or pager. Mode 4: CPU-to-CPU communication The EM241 modem module calls another EM241 module to establish a CPU-to-CPU connection. ** Multi can transmit 100 words PLC data. Configuration To set modes 2, 3, and 4, you need Micro/WIN programming software 3.2 or later, stock number 488-6454 Warnings
This product is in scrap mode and the manufacturer has now discontinued production. We recommend that you review the alternative products highlighted by the manufacturer. Also, see the list of cross-references in the Technical Reference section, which highlights the upgrade path for the current product.
Model parameter introduction
Attribute value
For use with Simatics 7-200
Module type modem
Voltage class 24V DC
The length is 71.2mm
Width 80mm
Depth 62mm
The dimensions are 71.2x80x62mm
