Rated input voltage
DC24V
Rated output voltage
DC24V
Rated output current
4X2-10A
Power phase number
direct current
Input voltage range
DC20.4-30V
environment condition
ambient temperature
During operation -25+ 70 ° C; Natural convection
During transportation -40+ 85 ° C
Storage period -40+ 85 ° C
The weather level complies with IEC 60721, and the weather type is 3K3, 5... 95% condensation
Mechanical device
Electrical connection specifications: straight plug terminal
At the input terminal 24V1, 24V2: plug-in terminal, 0.5 16mm ²; 0V1, 0V2: Direct plug-in terminal
, 0.5... 4mm ²
On the output end, 1-4: plug-in end, 0.5 4mm ²
● For signal contacts 13, 14: straight plug terminals, 0.2 1.5mm ²
● For auxiliary contact RST: straight plug end, 0.2 1.5mm ²
45 mm width of the outer shell
135 mm of the high temperature shell
125 mm deep shell
Installation width 45 mm
Installation angle 225 mm
Must adhere to spacing
● Up to 45 mm
● Lower 45 mm
● Left 0 mm
● Right 0 mm
Net weight 0.3 kg
Tightening type installed on DIN rail EN 60715 35x7.5/15
